Basic Info.
Certification
CE, ISO9001:2008
Injection Weight (G)
207 G
Plasticizing Capacity(G/S)
32
Screw Diameter (mm)
45 mm
Injection Rate (G/S)
137 G/S
Mold Height(mm)
145 - 400 mm
Ejector Stroke(mm)
100 mm
Product Description
POWERJET INJECTION MOLDING MACHINE
BJ126-V6/S6 w ith The New Driving System For Our Standard Injection Molding Machine, BJ Series Saving More Energy Than Before. The Motor Will Stop At The Stage Of Cooling For Saving Energy And Also Can Provide Higher Injection Accuracy And Speed.
Specification
DESCRIPTION
| UNIT
| BJ126-V6
|
Clamping force
| KN
| 1260
|
Opening stroke
| mm
| 350
|
Max.datlight
| mm
| 750
|
Platen size
| mm
| 610*610
|
Space between bars
| mm
| 410*410
|
Max.mold height
| mm
| 400
|
Min.mold height
| mm
| 145
|
Ejector stroke
| mm
| 100
|
Ejector force
| KN
| 42
|
Screw diameter
| mm
| 40
|
Screw L/D Ratio
| L/D
| 20
|
Injection Pressure
| MPa
| 166
|
Shot volume
| cm3
| 238
|
Screw stroke
| mm
| 190
|
Screw speed
| rpm
| 190
|
Hydraulic system Pressure
| MPa
| 17.5
|
Pump motor power
| KW
| 11/14
|
Heater power
| kW
| 6
|
Company Profile
FAQ
Q1: Are you a manufacturer or trading company?
A1: We are a factory for plastic machines. Over 24 Years Experience In Manufacturing Injection Molding Machine And Blow Molding Machine.
Q2: Delivery time
A2: Normally Machine Delivery from the factory in 0-60 days after receiving the down payment. (During Chinese Public Holidays like National Day or Chinese New Year, the delivery time should be 10-30 days longer accordingly).
Q3: Where is your factory located?
A3: Our factory is located in No.5 Chuangxin Xi Road, Leping Town, Sanshui District, Foshan City, Guangdong Province, China. 1h drive from Guangzhou to our factory. Welcome to visit our factory.
>>
