Hot Selling Low Price Automatic Granite and Stone Sand Mining 6cx European Jaw Crusher

Product Description

Product Introduction
6CX series jaw crusher is a new generation product successfully developed by finite element analysis method based on the most advanced crushing technology and research results in the world, based on decades of experience in jaw crusher design and manufacturing.
Compared with traditional jaw crushers, 6CX series jaw crusher pays more attention to details in design and manufacturing, adopts high-strength materials and advanced manufacturing technology, and has the advantages of higher structural strength, higher equipment reliability, larger crushing ratio, higher output and lower comprehensive processing cost.

Working Principle
The motor drives the belt and pulley to move the movable jaw up and down through the eccentric shaft. When the movable jaw rises, the angle between the toggle plate and the movable jaw increases, thereby pushing the movable jaw plate closer to the fixed jaw plate. At the same time, the material is squeezed to achieve the purpose of crushing. When the movable jaw moves downward, the angle between the toggle plate and the movable jaw decreases. Under the action of the pull rod and spring, the movable jaw plate leaves the fixed jaw plate, and the crushed material is discharged from the lower opening of the crushing chamber. As the motor rotates continuously, the movable jaw of the crusher performs periodic movements to crush and discharge materials, realizing mass production.
Specifications and Performance Parameters

Model	Size of Feed Opening(mm)	Motor Power(kw)	Speed(r/min)	Fixed jaw plate length(mm)	Max.Maintenance Weight(Kg) (Without Flywheel Moving Jaw Assembly)
6CX80	800×510	75	350	1100	2870
6CX96	930×580	90	300	1100	3500
6CX100	1000×760	90	260	1600	7060
6CX106	1060×700	110	280	1450	4020
6CX110	1100×850	132	230	1800	9000
6CX125	1250×950	160	220	2000	12960
6CX140	1400×1070	200	220	2100	15950
6CX145	1400×1100	200	220	2300	18600
6CX160	1600×1200	250	220	2500	21380

Applicable materials
medium and fine crushing of hard and medium hard rocks such as quartz, river pebbles, calcite, dolomite, granite, basalt, iron ore, limestone, diabase, bluestone, etc.
Company Profile
Henan Anshun Machinery Equipment Co., Ltd. is a modern enterprise engaged in the research and development, production, sales and service of equipment in the fields of mining crushing, building crushing, tower sand making, etc. It is the first unit to pass the ISO9001 quality certification system, the EU CE certification unit, and an enterprise with the right to import and export. Over the years, the company's products have been sold well throughout the country and exported to Vietnam, North Korea, Central Africa and the Middle East countries and regions. The company's after-sales service team is spread all over the world. The complete after-sales service management system has been recognized and praised by the industry, and is well-known at home and abroad, becoming a shining pearl in my country's mining machinery manufacturing industry. Packaging & Shipping
Certifications
FAQ
Support: We can not only provide the good machines, but also wholeheartedly provide the comprehensive for our clients. The series of professional technology service will make you have an excellent product experience. After-sales service support : After we signed the purchase contract and have a certain reputation guarantee, we will contact the professional group that responsible for ship bookings, commodity inspection, commercial invoices, packing list, insurance policy and so on, in order to provide you the perfect goods trading services, until the product you purchased properly to your hands. We will send a professional and high levels installation engineer team at the same time the product properly to the destination, in order to supply you a full range of products installation services. For some typical problems, our rigorous installed engineers also will do some certain installation debugging training, etc. Technological support : ANSHUN Machinery has been largely adopting new technologies, new techniques and high-tech equipment. And ANSHUN Machinery also has strict and effective quality control system. We have obtained ISO9001:2000, TUV and CEquality system certificate.

---
