Wafer & Lug Stainless Steel or Cast Iron Electric and Pneumatic Slurry Sluice Knife Gate Valve

Product Description

Fully Lug Slurry Knife Gate Valve (PZ71)
Manufactured under international Quality Assurance systems; Accredited with ISO 9001 and CE Quality Assurance Programmes.
Size Range: 2" to 42" N. B.
Pressure Classes: ANSI 150, PN6, PN10, PN16
End Connections: Flanged & WAFER
Materials (Standard)
Standard Constructions
Steel: Cast Carbon Steel A216 Gr WCB Body and Bonnet.
F316 Stem & Gate, Resilient or Metal Seating
Stem packing PTFE / graphite composite.
Iron: Cast Iron A126 GR. B Body and Bonnet.
F304 Stem & Gate, Resilient or Metal Seating
Stem packing PTFE / graphite composite.
Available also in low temperature steels, low alloy steels, stainless steels, duplex type stainless steels and other exotic materials.
Various trim materials available to suit service conditions.
Operation
Manual, Electric, Hydrau-Pneumatic Actuator
Standards Compliance
MSS SP-81, JB/T 8691
Face to Face Dimension: MSS SP-81
Pre-temperature Rating: ANSI B16.34
Flanged Dimension: ANSI B16.5, DIN2533; JB79; GB/T 9113; HG20592
Inspect & Test: API 598, GB/T 13927; JB/T 9092

DESGN & MFT.	MSS SP-81	ENDS CONNECTION	WAFER/LUG
PRE-TEP. RATING	--	INSPECT & TEST	MSS SP-81
F-F DIMENSION	MSS SP-81	END CONNECTION	ASME B16.5
MARKING	MSS-SP-25	BELLOWS CONFORMS	--
PAITING	TBA	SPE. REQUIREMENTS	N.A

Pictures
Final Inspection
Shipment

---
