Glassfiber Media High Temperature HEPA Filter with SUS Frame and Aluminum Separators
US$165.00-190.00
5 Pieces
(MOQ)
Basic Info.
Model NO.
1FRK
Efficiency
H13
Filtration Grade
HEPA Filter
Type
Panel Filter
Certification
En1822
Temperature
≤350ºC
Gasket
Glass Fiber
Sealant
Ceramic
Transport Package
Carton and Bubble Pack
Trademark
Comfort
Origin
China
HS Code
8421999090
Production Capacity
100000PCS
Packaging & Delivery
Package Size
60.00cm * 61.00cm * 31.00cm
Package Gross Weight
25.000kg
Product Description
Glassfiber Media High-Temperature HEPA Filter With SUS Frame and Aluminum Separators Product Description HEPA 13 filter for VERY high-temperature applications (e.g. sterilization tunnels) up to 350ºC as protection for clean processes. Stainless steel frame and aluminum separators give high stability of your production. Pleats are uniformly separated by corrugated aluminum separators incorporating a hemmed edge to prevent damage to the media. Product Parameters
Frame
Stainless Steel 304#
Separator
Aluminum foil
Media
Glass fiber
Gasket
Glass fiber
Sealant
Ceramic
Tolerance of pressure drop ±15% Other dimensions & gasket on request Type -1W= gasket upstream (standard)
Please note installation and assembly instructions! Due to the different thermal expansion coefficients of the individual filter components the ceramic potting may form cracks during the tempering process. At operating temperature (350ºC) these filters have an overall efficiency of 99.97% at 0.3μm, leakages are possible.
Features High-temperature HEPA Filter Filter class H13 acc. to EN 1822 (at 20ºC) High air velocity (1,5m/s) Maximum continuous operating temperature 350ºC 100% leak-free: individually scan tested at 20ºC High mechanical stability Detailed Photos Company Profile Being an H&V and Ahlstrom filter media dealer in the southeast of China, ZJY Trade Co. Ltd is confident to offer you the most reliable and effective filters for each different application. Thanks to the direct collaboration between the manufacturers and ZJY, we are capable of both designing and producing customized and standard filters as per your demand. The catalog in the showroom represents the most experienced products we supply, which we exported to more than 20 countries, covering almost every continent. Our factories are all located nearby, you can rely on our professional communication and efficient monitoring of the parts' quality and lead time. We are proud to offer you high-quality aftermarket products as value-priced alternatives to the parts and products sold by original equipment manufacturers. We are confident you will be completely satisfied and find our products to be fully equivalent in specification performance to the OEM products which we identify for your convenience on this site.
