Woodworking Adjustable Plywood Panel Edge Trimming Cutting Saw
Product Features
1.Used servo control system, no sensor, proximity switch, with memory function (remember the position of the sawing board), avoiding the phenomenon that the sensor and the proximity switch fail to saw the broken board, and avoid the cumbersome damage of the sensor proximity switch. . Traction with servo motor, two-axis linkage, fast speed, large output, arbitrary setting of the program, two people operation, greatly reducing labor costs.
2. The size of the sawing edge is adjustable from 3*6 to 4*8, and the machine can solve the problem of sawing edges of different sizes.
3. It is made of pure iron base, stable operation and high precision. It adopts imported bearings, circulating lubricating oil and long service life.
4. It adopts 8 pieces saw shafts and runs at 8200 rpm. It has underline function, which fully solves the problems of bottoming, burrs, core pulling, etc. The sawing edge is smooth and does not need polish.
5. Infrared positioning, automatic arranging, load-type rail sawing, four-cylinder positioning, high straightness on the edge of the board, no angle adjustment.
6. Automatic lifting platform, automatic stacking. Install the lifting platform plate limiter to solve the problem of uneven packing of the plates.
7. It has the effect of dust removal, which is environmentally friendly and clean.
8. It is used for particle board, MDF, plywood, blockboard, multi-layer board, fire board, melamine board, building formwork, plastic steel film board, bamboo board, fire-retardant board, packaging board and so on.
Control
| PLC/Servo |
| working thickness（mm） | 3-60 |
| working size（mm） | 915-1220 1830-2440 |
| speed (m/min) | 0-30 |
| power（KW） | 40 |
| cutting power（KW） | 7.5 |
