Cylinder Head Surface Grinder Price with Magnetic Chuck (M7140)

Product Description

Cylinder head surface grinder price with magnetic chuck (M7140 )
Product Application The machine is reasonable in structure, good rigidity, beautifulappearance, convenient operation.
Using precision plastic guide surface and precision scraping,grinding imported hydraulic transmission, drive by synchronous.
The main mechanical valve is a special valve grinder, is dividedinto two parts, the mechanical commutation control, throttle control.Throttle control part and unloading function, can realize the stationstart and stop.
Grinding can be all kinds of plane and complex shaped surface,suitable for motor without grinding the feed, according to user needswith a permanent magnet sucker or electromagnetic sucker.
The main specification:

Model	Unit	M7140	M7140*14	M7140*16	M7140*20
Max. workpiece to bi groud	mm	1000*400*400	1400*400*400	1600*400*400	2000*400*400
Longitudinal motion stroke(Hydraulic)	mm	1100	1500	1700	2100
Distance from table surface to spindle center	mm	575	575	575	575
Vertical feed wheel movement perr lap	mm	1	1	1	1
Vertical feed hand wheel per movement	mm	0.01	0.01	0.01	0.01
The maximum stroke of transverse motion	mm	450	450	450	450
Horizontal intrmittent movement speed(stepless)	m/min	0.5-3	0.5-3	0.5-3	0.5-3
Longitudinal velocity(stepless)	m/min	3--30	3--30	3--30	3--30
Spindle speeds	r/min	1440	1440	1440	1440
Wheell size(dia*width*bore)	mm	φ350*40*φ127	φ350*40*φ127	φ350*40*φ127	φ350*40*φ127
Grinding head motor power	kw	7.5	7.5	7.5	7.5
Total motor power	kw	11.5	11.5	13	13
oil pump motor power	kw	3	3	4	4
Max loadng capacity of able	kg	800	800	1000	1380
Net weight	kg	3800	4500	5000	6000
The machied surface of the base of parallelism	mm	1000:0.015	1000:0.015	1000:0.015	1000:0.015
Surface roughness	μm	Ra0.63	Ra0.63	Ra0.63	Ra0.63
Machine size	mm	2700*1640*2100	3100*1640*2100	4600*1800*2100	5250*1800*2100

Standard Accessories:
Coolant tank
Shandard electro magnetic chuck
Balancing arbor
Wheel flange
Wheel extractor
Leveling wedge and bolt
Tool box and tools
Standard grinding wheel
Working lamp
Wheel dresser shant(not include diamond pen)
Build inelectro magnetic chuck controller
Optional Accessories:
Product Details
Packing shipping
For machine: usually by sea;
For documents: by international express, eg. DHL,TNT or EMS.
For packing :Free fumigation plywood packaging steel base
our service
1. Technical support online service provided.
2. Technical files service provided.
3. Machine operation video provided
4. On-site training service provided.
5.Spare parts replacement and repair service provided.
6 All of the questions will be replied within 8 hours
7. If you need to develop products with your own specification, we can help you to work it out.
8. Always be honest, never lie to customer, and never declare anything we don't have
Company Information
Since 1996,20 years' history for machine tool manufacturing
10 years' history for export
Total 2 manufacturing bases in china
Sino-germany technology cooperation
Production of 8 categories, more than 130 kinds of products
Set up design&research center at TAIWAN
Exported to total 48 countries in the world covered most areas
One-stop shopping for nearly all other types' machine tools 1:How can I choose the most suitable machines ?
A: Please tell me your specifications ,we can choose the best model for you , or you can choose the exact model You can also send us the products drawing ,we will choose the most suitable machines for you .
2: What's your main products of your company?
A: We specialized in all kinds of machines ,such as CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machines ,Drilling Machine ,Radial Drilling Machine ,Sawing Machine ,Shaper machine and so on .
3: Where is our factory located? How can I visit there?
A : Our factory is located in Tengzhou City ,Shandong Province,277500 China. You are warmly welcomed to visit us.
4. What is your trade terms?
A : FOB, CFR and CIF all acceptable.
5: What's the Payment Terms ?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;
Irrevocable LC at sight .
6: What's the MOQ?
A: 1 set .(Only some low cost machines will be more than 1 set )

We want to know:
1.What's your Industrial Voltage?
2.We strongly suggest you to tell us size, material of your workpiece for our evaluation, if possible, better to send us workpiece drawing, so that we can recommend you most suitable model!
3.If need CIF Price, please kindly tell us the port of destination.
Eunice Zhang

Sales Department

Tengzhou BoRui cnc machine Tool Co.,Ltd

---
