Building Glass Tempered Clear Tinted Reflective Double Laminated Flat Insulated Glass Curtain Wall

Product Description

Building glass tempered clear tinted reflective double laminated flat insulated glass Curtain wall
The introduction of laminated glass
PVB laminated glass is also highly versatile, and can be used in a wide range of applications. It is commonly used in windows, doors, skylights, and curtain walls, as well as in automotive and transportation applications. Overall, PVB laminated glass is a reliable and cost-effective solution for ensuring safety, reducing noise, and providing protection against UV radiation. Its versatility and adaptability make it an ideal choice for a wide range of construction and transportation applications.
Step 1: Cutting the Glass
The first step in making laminated glass is to cut the glass sheets to the desired size and shape. This is typically done using a glass cutting machine, which uses a diamond-tipped wheel to score the glass surface and create a clean break.
Step 2: Cleaning the Glass
Once the glass has been cut, it is important to clean it thoroughly to remove any dirt, dust, or other contaminants that could interfere with the lamination process. This is typically done using a combination of water, detergent, and a squeegee to remove any remaining water droplets.
Step 3: Applying the Interlayer
The next step in making laminated glass is to apply the interlayer material, which is typically a layer of polyvinyl butyral (PVB) or ethylene-vinyl acetate (EVA) plastic. This material is sandwiched between two layers of glass and provides the strength and durability that makes laminated glass so valuable for safety and security applications.
Step 4: Heating and Pressing the Glass
Once the interlayer has been applied, the glass sheets are stacked together and placed in an autoclave, which is a large, high-pressure oven. The autoclave applies heat and pressure to the glass, causing the interlayer to melt and bond the glass layers together. This process is typically done at temperatures between 130 and 150 degrees Celsius, and can take several hours to complete.
Step 5: Trimming and Finishing
Once the laminated glass has been formed, it is removed from the autoclave and trimmed to the desired size and shape. The edges are then polished and finished to create a smooth, uniform surface that is free from any sharp edges or rough spots.
In conclusion, the process of making laminated glass is a complex and highly specialized process that requires careful attention to detail and a deep understanding of the properties and behavior of glass and interlayer materials. By following these steps, manufacturers can create laminated glass products that are strong, durable, and able to provide the safety and security that is needed in a wide range of applications.
Specification

Product Name	Tempered glass, laminated glass, toughened glass, tempered laminated glass, safety glass, low-e insulated glass units
Glass Items	Clear float glass, ultra clear float glass, low iron float glass, grey float glass, brown float glass, tinted reflective glass, low-e coating glass, solar control low-e coating glass
Specifications:	Max size: 8800x3300mm, Min size: 300x300mm Thickness range: 2mm-19mm PVB thickness: 0.38mm, 0.76mm, 0.89mm, 1.14mm,1.52mm Full tempered, half tempered(heat strenghened, full tempered with heak soaking processing Gas filling: Air, Argon, Kyron Particle sizes: 50x50mm Area: 3mm thick 30 pieces particles, 4-12mm thick 40 pieces articles Aluminium spacer: 6A, 9A, 12A, 16A and warm edge spacer with black or aluminium color Sealing sealant: polysulfide sealant or structural silicone sealant Shape: flat tempered glass, bent tempered glass, circular tempered glass, parallelogram, irregular shape tempered glass
Applications	Facade, shopfront, glass furniture, bathroom, glass shelf, glass partitions, glass balustrade, building and home appliance
Colors	Clear, extra clear, frosted, grey, brown, green, blue, blue grey, pink, dark grey
Packaging	Seaworthy wooden cases with paper interleaved and safety corner protection for each piece
Guarantee period	More than 10 years guarantee period for the tempered glass and lamiante glass and low-e insulated glass
Certificates	3C, ISO, EN12150, AS/NZS2208,SGS, ROHS, BV
