Hot Sale 5liter 7.5liter Plastic Juice /Water /Chemical Bottle Blow Molding Machine

US$38,000.00 1 Set (MOQ)

Basic Info.

Model NO.
ABLB75
Making Method of Parison
Extrusion-Blow Molding
Automation
Automatic
Computerized
Computerized
Certification
CE
Application
Bottle
Max. Product Volume
15L
Transport Package
Film Packing
Specification
CE
Trademark
APOLLO
Origin
Zhangjiagang City, Jiangsu Province, China
HS Code
8477301000
Production Capacity
540 PCS/H

Product Description


ABLB90II 4 gallon bottle blow molding machine was specially designed for making plastic water gallons, lubricant oil bottles, tool boxes, plastic drums, and other plastic containers not over 20L.
The features of this machine:
(1)It is suitable for producing PE, HDPE, PP, PVC so on, plastic containers and bottles in all shapes are available, the max. Product volume is up to 20L.
(2)Double station single die head design, Stable and efficient.
(3)Most components of the blow moulding machine are from famous world brand.
(4)Full automatic process with low power consumption, high efficiency, quick and safe operation, easy for maintenance.
(5)Multiple screw available for double layer or tranparent liquid lever line.
(6)Auto deflashing device available, can remove the extra parts of bottles.
(7)Auto lubricant system controlled by PLC.
(8)Special screw cut device available
Max. Product volume 20 liters
Out put capacity 2160~2400pc/day
Screw diameter 90mm
Screw L/D ratio 24 L/D
Screw drive power 45KW
Screw heating capacity 8 KW
No.of heating zone 4 zones
Output of HDPE 128KG/H
Oil pump drive power 11 KW
Clamping force 108KN
Max.size of mold 240-660mm
Mold stroke 530 X 550mm
Max.die diameter 180mm
Blowing pressure 0.6 mpa
Air Volume 0.9 M³/MIN
Cooling water pressure 0.3mpa
Water consumption 90 L/MIN
Size of Machine 4.2x3x3.1m
Weight of machine 11ton
