8m Width Plastic Waterproof Membrane Extrusion Machine

Product Description

8m Width Plastic Waterproof Membrane Extrusion Machine
Junsheng Brand machines, guarantee is 2 years and we offer Turn-key project.
Width: 8000mm
Layer: 1-3 PE layers, with or without geotextile lamination
Brief Introuction of Junsheng HDPE Geomembrane Line:
- Geomembrane thickness 0.3-5mm, width up to 8000mm.
- Cast film, not blow film, film stronger and unique thickness.
- 100% recycled material, low production cost.
- 2 extruders co-extrusion with 3-layer T die, automatic control
- Online geotextile lamination
Main Technical Specification of Junsheng Waterproof Sheet Machine:

Model		JS-TGM3000	JS-TGM5000	JS-TGM6000	JS-TGM8000
Suitable material		HDPE, PP
Screw dia.	mm	150	150×2	150×2	180×2
L/D ratio	L/D	33:1	33:1	33:1	33:1
Product width	mm	3000	5000	6000	8000
Product thickness	mm	0.2-2.5
Output	Kg/h	500	1000	1000	1200
Line speed	m/min	4--6	4--8	4--8	4--10
Installed capacity	KW	320	550	550	680
Power consumption	KW	160	300	300	400
Dimensions (L×W×H)	m	22×5×2.8	24×7×3.5	24×7.5×3.5	25×10×3.5
Total weight	T	19	25	28	35

More Photos:

---
