N95 Protective Face Mask Breath Valve Assembly Machine

Product Description

FRTB-ZH3 Face Mask Breath Valve Assembly Machine
Plastic cap parts join/assembling machine
Machine Features
1.Instead of Manual work,this machine can auto assembly 2 components of the valve and insert the rubber in one machine,It increase production efficiency.
2.The machine can assemble at speed of 4000-5000 pcs per hour, whickh is fast and clean.
3.Especially for the products need to meet high requirements on the sanitary condition,it can avoid second-pollution.
4.Automatic Counting device installed, which you can preset the quantity per package,when it reach the quantity, the machine can stop automatic, it can increase your working efficiency and accuracy.
5.Adopts Auto vibrator sorter and feeder, which can make the dis-ordered caps in order and in correct direction, to ready the caps for main machine.
6.The Electric control system we use Variable Frequency Control Technology ,which is much more easy operate,stable,widely used, and longer using life.
7.This machine meet "GMP"and "CE" standards.
Structure of Equipment
Automatic cap sorting machanism: it puts the messy caps in order and makes all cap mouth upwards
Cap delivering amchanism: it delivers the ready cap into the cap assembly machanism in order and correct way.
Cap assembly machanism: it combines 2 pieces and completes the assembly process.
Main Technical Parameters

Productivity capacit	60 pcs/Min
Power	2.8 KW
Rated Voltage	220V,Single Phase
Compressed air	0.5m³/hour 8kg pressure
Machine Size	2000mm×2000mm×1500mm
G/N.W.	900/700KG

Our Factory
Machine PackingWe customize all kinds of non-standard bottle cap processing equipments:
More Details , Kindly contact us.
Attn:Becky Pan
Location: (Zhixin Industrial Zone)C-13-12, Ruian, Wenzhou City, Zhejiang Province
By Flight: Arrive at Wenzhou Airport
By Train: Arrive at Ruian Station

---
