Product Usage and FeaturesR800 Integrated Rebar DetectorUsage:The integrated rebar detector is a portable non-destructive testing instrument, which are mainly used for detecting the internal reinforcement position, the protective layer thickness, reinforcement spacing and diameter of rebar.It is characterized in coil structure design, faster speed, higher accuracy, stronger.It can tests thickness of concrete cover and rebar diameter location.GTJ-R800 Integrated Rebar Scanner can accurately draw the distribution map of the whole rebar, to provide test data with high precision and high speed.ParametersProductConcrete cover meter rebar locatorModelGTJ-R800Rebar dia. setting rangeφ6mm~50mmScope of rebar dia. estimationφ6mm~32mmConcrete cover test range1~240mmSmall range1mm~80mmLarge range1mm~210mmSuper Large range1mm~240mmMax. allowable errors of the Protective Layer Thickness1-80mm (±1mm)81~120mm (±2mm)121~210mm (±4mm)211~240mm (±4mm)Profile measurement functionSupportMesh measurement functionSupportWaveform measurement functionSupportprobe self-calibrationSupportHost parametersScreen size: 2.8 inch Resolution: 240*320Volume: 220*93*110mm Weight:0.6KGData transmission modeTF card; wireless cloud transmission (potional)Power suppyLithium batteryStorage capacity2000 Components *1000 Measuring pointsWorking environmentTemperature: -10℃ ~ +40℃ Humidity：≤ 90%RHDetailed ImagesFeatures1.Integrated design, small and easy to carry.;2.Thickness detection mode is intuitive, showing thickness and steel spacing at the same time;3.Thickness detection mode can automatically store thickness and spacing, which greatly improves the detection efficiency;4.The waveform scanning mode also shows the thickness and spacing of the rebar protective layer;5. 2.8 inch high resolution color screen;6. Large storage capacity TF card;7. With professional data analysis software, data processing and report generation can be easily done at PC.It can tests thickness of concrete cover, rebar diameter and location.It can accurately draw the distribution map of the whole rebar, to provide test data with high precision and high speed.ApplicationContact USCangzhou Lovely Technology Co., Ltd.It is specialize in Nondestructive Test Instrument and Material Test Machine over 12 years. With advanced technologies and best customer service, our product has exported to over 100 countries and regions, which win favorable comments from customers worldwide.Our equipment is used throughout the world for testing soil, concrete, cement, asphalt and aggregate materials. This testing involves evaluations of materials, which are used in construction projects ranging from roads, bridges and tunnels to dams, earthworks, airports, railways, etc.We adhere to the high standards of product quality, strict requirements, adopting the world-class production equipment, advanced management and production experience, developing the high-quality testing equipment.Our Customers and patent certificatePacking & DeliveryWhy Choose us ?1. Get our in-time reply via email or telephone or instant messenge. Our product specialist will guide you find the suitable product according to your requirement;2. Get best product with excellent quality and competitive price;3. One year guarantee for whole machine and in time technical support by video or email. Always enjoy our considerable & full-side after-sales service;4. Feeling very convenient since we can help you source and ship products from different factories via one shipment, which is significant to save your time and cost;5. Easily make the payment via West Union, Paypal, Credit Card for small value order;
>>
