Universal cutter head with 2 levels can be adjusted to virtually any angle (HURON System)
| SPECIFICATION | UNIT | X6236 |
| Spindle taper | | 7:24 ISO40(V);7:24 ISO50(H) |
| Distance from spindle center line to column surface | mm | 350~850 |
| Distance from spindle nose to worktable | mm | 210~710 |
| Distance from spindle center line to worktable | mm | 0~500 |
| Distance from spindle center line to arm | mm | 175 |
| Spindle speed | r/min | 11steps 35~1600 (V) ;
12steps 60~1800 (H) |
| Worktable size | mm | 1250×360 |
| Worktable travel | Longitudinal | mm | 1000 |
| Cross | mm | 320 |
| Vertical | mm | 500 |
| Worktable longitudinal/ cross power feed | mm/min | 8steps 15~370 ;Rapid:540 |
| Worktable elevating power feed | mm/min | 590 |
| T Slot | Number | mm | 3 |
| Width | mm | 18 |
| Distance | mm | 80 |
| Main motor | Kw | 2.2 (V) 4 (H) |
| Worktable power feed motor | W | 750 |
| Worktable elevating motor | KW | 1.1 |
| Coolant pump | W | 90 |
| Coolant flow | L/min | 25 |
| Overall dimension (L×W×H) | mm | 2220×1790×2040 |
| Net weight | kg | 2400 |
