US$13,000.00-18,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Storage Objects
Solid, Liquid, Gas
Transport Package
Wooden Case/Wrapped in PVC Film
Specification
Customized as request
Trademark
Chengyi technology
Production Capacity
200sets/Year
Product Description
Product Description
Product Parameters
Equipment Diameter | Tube Spec. | Tube QTY. | Note: max. number of tubes, and single tube pass as example |
Effective Heat Transfer Area (M2) |
Straight Tube Length (mm) |
1500 | 2000 | 2500 | 3000 | 4000 | 6000 |
DN300 | φ19.05 | 105 | ~9 | ~12 | ~15 | ~18 | | |
φ25.4 | 57 | ~6 | ~9 | ~11 | ~13 | | |
DN500 | φ19.05 | 308 | ~26 | ~35 | ~44 | ~53 | ~72 | |
φ25.4 | 182 | ~21 | ~28 | ~35 | ~42 | ~57 | |
DN700 | φ19.05 | 640 | ~54 | ~73 | ~92 | ~111 | ~149 | ~226 |
φ25.4 | 372 | ~42 | ~57 | ~71 | ~86 | ~116 | ~175 |
DN1000 | φ19.05 | 1345 | | ~152 | ~193 | ~232 | ~313 | ~473 |
φ25.4 | 810 | | ~122 | ~155 | ~187 | ~253 | ~382 |
DN1200 | φ19.05 | 1940 | | | ~278 | ~335 | ~451 | ~683 |
φ25.4 | 1180 | | | ~226 | ~273 | ~367 | ~555 |
Main Products The heat exchanger can be designed and manufactured as per Customers' drawings or requirement.
Type | Fixed tube-sheet heat exchanger | Floating head heat exchanger | U-shaped tube heat exchanger | Kettle heat exchanger | Double tube-sheet heat exchanger |
Material | 304/304L,316/316L 2205, TA2/TA10, Q345R,09MnNiDR, N06200, C71500, R60702 ,N10276, N08810, BFe30-1-1, etc. stainless steel , nickel alloy, titanium alloy, copper-nickel alloy, zirconium, and their clad materials |
Standard | ASME GB |
Process | evaporating, heating, condensing, cooling process |
Application | Petrochemical, energy lithium battery, ultra-clean & high-purity electronic chemicals, fluorine chemical industry, environmental protection, fine chemical, pharmacy, dye, paints & other industries |
Main Products:
Company Profile
About us we are specialized in the design andmanufacture of non-standard equipments,incl. heat exchanger, reactor, tower reactorstorage vessel, pressure vessels, internal, andskid mounted. Our advantage Our plant is 22,000 m2, with full-process production line from cutting, forming, welding, heat treatment to pickling and painting. There are non-destructive testing and mechanical property test laboratory, etc., and large-scale equipment such as laser cutting machine, non-ferrous metal plate rolling machine, hydraulic press, and high-temperature heat treatment furnace that can meet 1000°C. |
Packaging & Shipping
Shipping packaging: Transport saddle, and equipment transportation nitrogen filling protection (including blind for eachflange, equipment nitrogen filling). |
Certifications
We have many certificates such as ISO Certificates: 1. ASME Certificate 2. A2 Certificate 3. ISO Certificates |
Patents
FAQ Q1: I haven't done business with you before, how can I trust your company?
A: We have been in manufacturing industry for over 15-20 years. The new factory is built according to the industry's
high standard of 1%.
Q2: What is the minimum order?
We manufacture non-standard equipment according to customer requirements. Order of 1 piece is acceptable.
Q3: How can I get a sample to check your quality? How long can I get the sample?
We do not provide samples because the vessel and equipment are non-standard.
Q4: What payment terms does your company accept?
A: We accept advance payment, T/T, L/C.
Q5: What's the shipment terms and delivery time of your company?
A: FOB, FCA, CFR, CIF. 120-180days.
Q6: Do you give any discount?
A: We'll try our best to offer the best price and good quality at the same time.
>>
