| 1WG4.0-FC SPECIFICATION | ||||
| | Item | Unit | Standard | |
| 1 | Engine | Model | / | 178F |
| Rated power | KW | 4 | ||
| Engine speed | r/min | 3600 | ||
| 2 | Power tiller | M.T | mm | 1210X690X1030 |
| Weight | kg | 115 | ||
| Displacement | ml | 406 | ||
| Working width | cm | 105 | ||
| Working depth | cm | ≥10 | ||
| Working speed | m/s | 0.1-0.3 | ||
| Hour production | hm²/h·m | ≥0.04 | ||
| Fuel consumption | kg/hm² | ≤25.0 | ||
| Drive way | / | Gear | ||
| Connection method | / | Direct coupled gearbox | ||
| 3 | Roll turning | Designed speed | r/min | First Gear:115;Second Gear:137 |
| Blade diameter | mm | 180 | ||
| Total number | Piece | 24 | ||
