Biomass Energy Rice Husk Pellet Plant with CE Certification

Product Description

Biomass Energy Rice Husk Pellet Plant With CE Certification

Features of complete wood pellet production line
1.The complete pellet line with reasonable structure as your actual need and working space.
2.The produce capicity of complete pellet line is high and customized.
3.The complete pellet line works stably and continuously, all machines can be interlocked, safe and easy to operate.
4.The complete pellet line produce high quality wood pellets with European standard.
5.The complete pellet line works with electric power, high efficiency and low cost.
6.This complete pellet line is suitable for kinds of materials such as wood dust, straw, grain husk, seed sheel, sugarcane bagasse and so on.

Model	Power(KW)	Capacity(T)	Weight(T)	Size(mm)
TYJ551-II	90-110	1-2	5.5	2364*1550*1705
TYJ551-III	132	2-2.5	5.5	2364*1550*1705
TYJ760-III	160/185/200	2.5-3.5	9	2564*1750*2150
TYJ860-III	220-250	3-5	13.5	2664*1950*2150

Processes of complete wood pellet production line The complete wood pellet production line through our research and design is manufactured for produce the wood pellets, Main equipments within it include Wood Crusher, Dryer, Storage bin, Screw Conveyor , pellet mill, Hoisting machine, Cooling and dusting machine and Packing machine. It has advantages such as compact structure, good appearance, high yield, less consumption, convenient and reliable performance etc.
Detailed explanation of wood pellet production line
1.Crushing Process
a. If the raw material is big wood log with bark,we need wood debarker machine and wood splitter machine to make the wood with small size.
b. If the thickness of raw wood material is >10mm, and >50 * 50mm(L * W), we need use the Wood Chipper to chip them into small pieces.

Main Crushing Machines:
1.Log splitter
2.Sawdust Chipper
3. Drum Chipper,Wood Pallet Crusher
4.Mobile Branches Grinder
5.Chaffer Cutter
6.Palm Fiber Making Machine
2.Grinding Process
The chips or small size raw material are ground by hammer mill to particle size less than 5mm suitable for pelleting.
Main Grinding Machines:
1.High efficiency Hammer mills
2.Multifunctional hammer mills
3.Wood Crusher
4.Straw Hammer Mill
5.Straw Rotary Chopper
3.Drying Process
Rotary Dryer includes Stove and Main Rotary Dryer, which can reduce the moisture from 50% to 10%. Our stove is fueled by coal and biomass fuel, saving electrical energy largely.
(client can build the hot stove by self, and we provide its drawing)
The moisture content of raw materials must be controlled :10%-15%.
Main Drying Machines:
1.Rotary Drum Dryer
2. Air Flow Dryer
4.Pelleting Process
Pellet mill machine is the most important equipment : Press raw material into pellet.
Raw material: hard wood, waste wood and straws, woodchips(palm, mahogany,rubber tree), bamboo shavings, rice husk, peanut shells, wheat straw, corn stalk, cotton stalks, alfalfa grass, bagasse, palm fiber.
Main Pelleting Machines:
1.TYJ series Ring Die pellet mills
2.Skj series Flat Die pellet Milll
5.Cooling Process Complete closed structure, stainless sieve,
low noise and stable operating

Main Cooling Machines:
1.Cooler Separator
2.Simple cooler
6.Packing Process
In this process, we suggest our Semi-Auto Packing Machine to you.
The weighting scope of this machine is 15kg-50kg
per bag.

Main Packing Machines:
1.Ton Packing Machine
2.Automatic Packing Machine
3.wood Shavings Bales

Certifications of complete wood pellet production line
Welcome to TONY Company
Dear friends, in order to help you choose the most suitable machine, pls tell me the following information:

1. What's the capacity you want?

2. What's the raw material?

3. What's the size of the raw material?

4. What's the moisture content of your raw materials?

5. What's the final pellet size do you want?

6. Automatic packing or manual packing needed?

7. What's your country voltage?


Our promise to you...
I promise to provide a high quality product at a fair price that will last for years and years, shipped as quickly as possible along with professional engineers support you require to get you up and running. You can call me anytime on trademanager. I'm always working and I never sleep! (Ok, maybe sometimes.) All the parts of products are rechecked before transportation, therefore the clients will receive the best quality products.. Free consulting service, please contact us when you have any questions about biomass pellet machinery. We can also supply for the pellet machines as following:
1. The SKJ Series flat die pellet mill with the volume 100kg to 4 ton per hour.
2.TheTY Series ring die pellet mill with the volume 800kg to 5 ton per hour.
3.The SKJD Series Pellet Mill with Diesel Engine with volume 100kg to 400kg/h.
4.The SKJT Series Pellet Mill with Tractor Engine with volume 80kg to 400kg/h.
5.Hammer Mill
6.Wood crusher7.Wood chipper8.Drum dryer9.Packing machine10.Whole pellet making production line from the volume 0.5 ton to 20 T/h.

---
