| Max. Working Pressure | 1.6Mpa |
| Temperature Class | T30 |
| Accuracy Class | ISO 4064, Accuracy Class 2 |
| Body Material | Stainless SS304(opt. SS316 or SS316L) |
| Battery Life | 6 Years (Consumption<0.6uA) |
| Protection Class | IP68 |
| Environmental Temperature | -40~+70℃,≤100%RH |
| Pressure Loss | ΔP16, ΔP25 |
| Climatic And Mechanical Environment | Class O |
| Electromagnetic Class | E2 |
| Communication | RS485(ModBus), M-bus, NB-IoT, Opt. OCT Pulse |
| Display | 8 digits LCD display volume(m3,L,GAL), flow rate(m3/h,L/min,GPM), low battery power alarm, flow direction, output. |
| Connection | Thread Connection |
| Flow Profile Sensitivity Class | U5/D3 |
| Data Storage | Store the data of Day, Month and Year. The data can be permanently saved even power off. |
| Frequency | 1-4times/second |
