Advanced Plastic Rigid Thermoforming Machine for Quality Production
US$150,000.00
1 Set
(MOQ)
Basic Info.
Model NO.
HLRCH-850 HLZCZ-850
Assembly Structure
Separate Type Extruder
Screw
Twin-Screw
Engagement System
Intermeshing
Screw Channel Structure
Deep Screw
Exhaust
Don′t Exhaust
Automation
Automatic
Computerized
Computerized
Capacity
450-550 Kgs
Material
PS Foam
Thickness of The Sheet
1.5-6mm
Screw Type
Two
Transport Package
PE Film Packing
Specification
5mx4.5mx3m
Trademark
Holin
Origin
China
Production Capacity
15 Sets
Product Description
PS Foam Sheet Extruder Machine The PS foam sheet extruder is the foundational step to creating final products. Therefore, it is crucial for initiating the production process. We are experts in the PS foam sheet industry in China, boasting extensive experience in meeting customer requirements. Our primary market is the South America region. We warmly invite you to discuss your needs with us and visit our factory. Machine Features: - Precisely designed screw - Equipped with accurate extrusion elements - Specially designed rear section of the secondary extruder ensuring no leakage - Computer-controlled cooling water system for the secondary extruder, ensuring superior cooling - Unique die and air ring for consistent thickness and sheet quality - Ability to store all technical parameters Model Parameters Unit HLSJPS-130/170 Capacity kg/hr 450-550 Thickness mm 1.5-6 Sheet Width mm Double sheet 1000-1500 Foam Rate times 11-30 Density kg/m 332.5-90 L/D 37/1, 38/1 Cooling Air cooling for primary extruder, water cooling for secondary extruder Linear Speed m/min 5-40 Central Height mm 1100 Cooling Water Pressure Mpa ≥0.3 Cooling Water Volume t/h 20 Compressed Air Pressure Mpa 0.7-0.9 Compressed Air Volume m 3/min 2 Butane Gas Pressure Mpa 1 Installed Power kw 625 Installed Size m 40x4.5x3 Weight t 32
