| US$53,500.00 | 1 piece (MOQ) |
| Technical parameters | Unit | SC200/200 | |
| Height | m | 300 | |
| Rated load | kg | 2000/2000 | |
| Maximum capacity | 9 /9 | ||
| Boom lift wweight | kg | ≤200 | |
| Lifting speed | m/min | 0-45 | |
| Electormotor | Model | YZEJ132ML-4 | |
| Power | kw | 15*2 / 15*2 | |
| Speed-limiter | Model | SAJ40-1.2A | |
| Rated tripping speed | m/s | 1.2 | |
| Standard motion speed | m/s | 1.1 | |
| Rated automaticload | KN | 40 | |
| Type | gradual | ||
| Reducer | Model | SWC1 | |
| Center distance | mm | 125 | |
| Speed radio | 1:12 | ||
| Bracking distance | m | 0.3-1.2 | |
| Max lnclination of frame | angle | 0-15 | |
| Mast section dimension | mm | 650×650×1508 | |
| Crane cage inner net dimension | m | 3.2*1.5*2.2 | |
| Guardrail dimension | m | 5.93*3.62*1.82 | |
| Hoistway dimensions | m | ||
| Free end height of the guide rail frame | m | ≤4.5 | |
| Gounterweight weight | kg | 1100 | |
| Direct attached frame | Installing interval | m/set | 4.5 |
| Distance between two embedded parts | mm | 1488 | |
| Installation dimensions from center of rail frame to building wall | mm | 2800-3200 | |
| Safe and protection system | Upper and below limited switches,upper and below limit utmost switches,gate limited switch,falling avoiding safe device,cushion device,safe lock of gate,counterweight rope breaking or loose protecting device,safe hook,The safety device against overload,Anti-punching standard section etc. | ||
