Fanuc Bed Type CNC Milling Machine

Negotiable 1 set (MOQ)

Basic Info.

Model NO.
KBM-1654
Structure
Bed type
Milling Cutter Type
Vertical Milling Cutter
Controlling Mode
Artificial
Automatic Grade
Manual
Precision
Precision
Certification
CE, ISO 9001
Condition
New
Name
Vertical Millng Machine
After-Sales Service Provided
Engineers Available to Service Machinery Overseas
Delivery Time
About 60days
Warranty Period
One Year After Delivery
Voltage
as Your Request
Color
as Your Request
CNC or Not
Normal
Transport Package
in Wooden Case ( Can Be Fumigated) / Plywood Case
Specification
CE norms, ISO9001: 2008
Trademark
TIMAC
Origin
China (Mainland)
HS Code
84595900
Production Capacity
80 Sets Per Month

Product Description

FANUC Bed Type CNC Milling Machine KBM-1654
Features:
1. The spindle system features strong rigidity, it is suitable for rough machining and force cutting, hence improve machining efficiency, features long travel, heavy loading.
2. The milling machine can be used for drilling, boring, lathing and milling.
3. The milling machine adopts rectangular guide ways, features strong rigidity and high accuracy.
4. Radial tool holder of facing head on the headstock head for radial machining.
5. Optional digital readout device, reading accuracy 0.01mm, positioning accuracy 0.05mm.

Standard accessories:
Semi-isolated table shield, Cutting fluid circulation system, Auto. Lubrication system,
Spindle air flow,Working light, Level adjusting screw and block, Clamping apparatus.

Optional accessories:
The forth axis revolving table, Vertical arm type ATC, Full closed safety cover,
Cutter length measuring unit, Edge finder, Shank

Technical Parameters

Specification KBM-1354B KBM-1654 KBM-2063 KBM-2473
Table size(L×W/mm) 1370×330 1370x406 1600x510 1854x610
Table loading capacity(kg) 400 800 1200 1500
T-slots(W/mm×NO) 16×3 16x5 18x5 18x5
X-axis(mm) 800 1000 1200 1500
Y-axis(mm) 450 480 700 700
Z-axis(mm) 480 600 600 700
Max.move speed(mm/min) 8000 8000 10000 10000
Max.feed speed(mm/min) 3000 3000 4000 4000
Spindle speed(rpm/min) range:40~6000
Spindle nose BT40 BT40 BT40/BT50 BT40/BT50
Spindle motor(kw) 5.5 7.5 7.5 7.5
Servo motor(kw) X/Y:1.0,Z:1.5 X/Y/Z:1.5 X/Y/Z:2.0 X/Y/Z:2.0
Spindle quill diameter(mm) 120 150 150/160 150/160
Spindle to column surface(mm) 450 520 640 695
X-axis(mm) 32×5p4Double nuts 32×5p4Double nuts 40×10p4Double nuts
Y-axis(mm) 32×5p4Double nuts 40×5p4Double nuts 40×10p4Double nuts
Z-axis(mm) 32×5p4Double nuts 40×5p4Double nuts 40×10p4Double nuts
Positioning accuracy(mm) ±0.015 ±0.015 ±0.015 ±0.015
Repeatability(mm) ±0.008 ±0.008 ±0.008 ±0.008
Packing dimension(L×W×H)(mm) 2250×2280×2450 2500x2280x2650 2900x2950x2800 2900x3150x2900
Machine weight(kg) 2600 3800 5000 6000


Our Advantages
1. Free replacing parts available in the warranty period. Cost price replacing parts available beyond the warranty period.
2. Quick action and reply for the technical questions at any time in the whole life of the machine.
3. Overseas after service center available in some region.
4. Engineer overseas service available on the requirement of customer(relative cost born by customer).
Packaging & Shipping
Company Profile
Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.
Since the establishment of the Ministry of Foreign Trade, we have participated in various domestic and international exhibitions such as the Autumn Canton Fair, Beijing Exhibition, Shanghai Exhibition, Moscow, Ethiopia, and Russia, and have maintained long-term friendly cooperative relations with exhibition customers.
Customer visited
So far, we have received many customers from abroad, and they are all very satisfied with our company and products
The following is one of the most satisfactory products recommended by customers, as well as our main product categories. you can click and view

Conventional Lathe CNC Lathe
CNC Machining Center
CNC Milling Machine
Grinding Machine Milling Machine
Special Use Lathe Boring Machine

FAQ
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price;
2 . Professional R&D team and 25 years export experience;
3 . Exported more than 60 countries;
4 . CE, ISO Certificates;
5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager);
6 . 12 months quality warranty;
7 . Oversea engineers available for problem resolving;
Q: Do you have QC or any safety standards for your machinery?
A: yes, we have established a highly strict quality control department to guanrantee good quality.
Q: What's the MOQ?
A: 1 set (Only some low cost machines will be more than 1 set )
Q: What about the payment terms?
A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment;
(2) Irrevocable LC at sight;
(3) Western Union, MoneyGram, etc.
Q: How about the warranty?
A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
