High Precision Woodworking Router with 3.0kw Water Cooling Spindle

Product Description

Product Parameters
Introducing the Wayne CNC Router Machine, a true masterpiece in the realm of intelligent cutting and milling. This technological marvel is crafted with unparalleled precision, addressing a diverse spectrum of complex processing needs with extraordinary versatility. Whether it's routing, drilling, cutting, sawing, slotting, or more, this exceptional machine excels in all. It is equipped with a cutting-edge carousel tool magazine, strategically integrated beside the spindle or along the fuselage. This groundbreaking feature enables automatic tool changes, allowing for multiple intricate processes to be executed with effortless precision in one seamless operation. From cutting and engraving to drilling, grooving, and pocketing, it adeptly handles an extensive variety of materials, including wood, MDF, acrylic, PVC, plastic, foam, and beyond.

Description	Parameter
X,Y,Z Working Area	1300x2500x200mm, ect.
Spindle type	3kw water cooling spindle, ER20
Inverter type	3.7kw Fuling inverter
Control system	Mach3 control system
Driving system	Stepper 450B and Leadshine 860H drivers
Machine structure	Heavy duty welded steel frame
Work table	Aluminum T-slot working table with water sink
Cooling system	Water cooling spray
Linear guide	Taiwan Linear guide
Lubrication system	Manual lubrication system
Tool Calibration	Manual tool sensor
Cables	Germany lgus cables with CE, cUL certificate
Compatible Software	Artcam, Aspire, etc.
Command Language	G Code
Control System	Mach3 control system
Traveling speed	30m/min
Working speed	0-15m/min
Re-positioning accuracy	±0.05mm
Working Accuracy	±0.05mm
Working voltage	220V 1PH/3PH 50HZ/60HZ 380V 3PH 50HZ/60HZ

Discover the advanced 1325 CNC Router, engineered with robust features specifically for wood cutting. This innovative machine can be meticulously customized to ensure it aligns perfectly with your unique specifications. It guarantees not only optimal functionality but also peak performance, tailored precisely to meet your individual needs and expectations.
Product Description
The Wayne CNC router machine is a game-changer for enterprises aiming to boost production efficiency. This cutting-edge machine transforms the traditional tool-changing process with its innovative independent tool magazine, housing a diverse array of tool bits. Guided seamlessly by advanced computer software, it switches tools automatically, ensuring an uninterrupted, highly efficient workflow with exceptional processing capabilities.
1. Wood Processing: This machine excels in handling an extensive variety of furniture components, from doors and windows to cabinets and screens. Every piece is crafted with unparalleled precision, making it an exceptional choice for woodworking projects. 2. Advertisement: Specifically engineered for precision engraving and cutting of various labels and number plates, it consistently delivers impeccable results on every project.
3. Art Crafts: Expertly carves characters in any language and intricate designs on gifts and souvenirs, showcasing outstanding craftsmanship and meticulous attention to detail.
Defining Features
1. With a Z-axis feeding height of 200mm, it ensures optimal performance and adaptability across a wide range of applications, significantly boosting your production capacity.
2. Built with a sturdy square tube welded steel frame structure, boasting an impressive 8mm wall thickness for maximum stability and long-lasting durability.
3. Features the choice between an Aluminum T-slot table or a Vacuum table, paired with a robust 5.5kw Vacuum pump for unparalleled support and efficiency.
4. Incorporates an X-axis rack and pinion drive, a Y-axis dual rack and pinion drive, and a Z-axis 2510 Ball screw, ensuring precise and fluid movement for seamless operation.
5. Outfitted with top-tier X, Y, Z axis Taiwan square rails from PMI, guaranteeing smooth and precise operations with every use.
6. Comes standard with a dependable 450B stepper motor and MA860H Leadshine driver, with an optional upgrade to a servo motor and driver for enhanced control and superior performance.
7. Equipped with a powerful 3.0KW water cooling spindle and a 3.7kw Fuling inverter, with additional spindle options available to customize solutions to specific needs.
8. Integrated with the Nc-Studio-5.4.49 control system, offering optional DSP or Mach 3 configurations for personalized and flexible control solutions.
Enhanced Options
1) Upgrade to a 4.5kw water cooling spindle to significantly boost efficiency and performance;
2) Select from rotary axis options with diameters of 80mm, 100mm, 150mm to expand your machine's capabilities;
3) Choose the Mach3/DSP control system for versatile and adaptable operational control;
4) Add a dust collector to maintain a pristine and efficient working environment;
5) Equip the vacuum table with a powerful 5.5kw vacuum pump for superior material handling and support.
Detailed Photos
1325 CNC ROUTER
Optional 1530, 2030, 2040 machine dimensions available; customizable to fit your specific needs.
# Working area dimensions: 2500*1300*200mm, offering ample space for versatile projects. # Robust heavy steel welding structure for enhanced durability and stability.
# Dual-function Table: Vacuum and T-slot, maximizing material hold-down efficiency.
# Equipped with a reliable Fuling inverter for seamless power management. # Advanced two-bag dust collector for a cleaner, safer work environment. # Powerful 5.5KW vacuum pump ensures secure material handling. # Artcam Software: User-friendly, versatile software for intricate design projects. # Safety first with France contactor and leakage protector integration. # Automated oil lubrication system for consistent performance and maintenance ease. # Precision Japan Omron limit switch for enhanced machine accuracy. # Precision tool sensor for quick and accurate tool calibration.
# DSP A11 control system for robust, efficient machine management. # 3.0KW water cooling spindle, ensuring optimal temperature control during operations. # Leadshine step motor and drivers for precise and reliable motion control. # Taiwan HIWIN square guide rail for smooth, high-precision linear movement. # Taiwan TBI ball screw for superior accuracy and load capacity. # High precision rack and pinion system for seamless operational efficiency.
2. Reinforced construction of the portal supports
The portal is mounted on high-strength cast iron supports, significantly boosting rigidity and deformation resistance. Its innovative 'T' shaped base with six mounting holes enhances load capacity without sacrificing processing quality.
3. High-precision linear guides 'THK' from Japan offer unmatched stability. These guides ensure precision movement of the gantry, caliper, and high-speed spindle along the X, Y, and Z axes, delivering excellent processing accuracy and extended machine life without compromising performance.
4. Industrial electric spindle 6.0 kW - 18,000 rpm, designed with cutting-edge solutions from the world's leading manufacturers.
This spindle's high rotation speed (up to 24,000 rpm) and increased power allow efficient processing of wood, chipboard, MDF, plastic, acrylic glass, and more, producing high-quality finished products.
5. Control panel DSP A11
This ergonomic control panel is designed for easy manual operation, simplifying machine adjustments and minimizing risk to machinery during processing.
The DSP A11 control system from Taiwan is highly reliable and cost-effective. It supports full 3D processing and simplifies program editing and creation directly on the machine. Its intuitive graphical interface boosts productivity and product quality, while USB and Ethernet interfaces facilitate easy connection to external devices and integration into a local network.
6. Leadshine servo motors from Japan
These motors, installed for X, Y, and Z axis movement, enable high-speed precision positioning of the spindle (up to 0.001 mm) and speeds up to 20 m/min. Renowned for reliability and stability, they excel even under challenging production conditions. Perfect for high-speed, heavy-duty machinery, including five-axis equipment. A high-performance oil-free plate-rotor vacuum pump ensures secure material fixation, allowing for maximum feed rates without part displacement risk.
7. Control cabinet

Packaging & Shipping
Company Profile
Liaocheng Wayne New Materials Co., Ltd. is a beacon of innovation and excellence, reigning supreme in the realm of CNC Router and Laser Engraving & Cutting technology. Nestled in the dynamic and forward-thinking city of Liaocheng, Shandong, our extensive and diverse product range is a testament to state-of-the-art machinery. Our offerings include Large-scale ATC Woodworking Router Machines that set new benchmarks in efficiency, and sophisticated 5-axis CNC Router Machines that deliver unmatched precision. We present reliable CNC Advertising Router Machines for flawless branding endeavors and precise CNC Marble Engraving Machines for exquisite stone artistry. Industrial applications are powered by our efficient CNC Plasma Cutting Machines, while our cutting-edge CNC Metal Mold Machines cater to intricate demands. Our versatile lineup also features CNC Lathe Machines, Swiss Type Lathe Machines known for high precision, robust Fiber Laser Cutting Machines, adaptable CO2 Laser Cutting & Engraving Machines, state-of-the-art Laser Marking Machines, and highly effective Laser Welding Machines, among others. By leveraging breakthrough technology and adhering to stringent quality standards, we are committed to fortifying the global brand 'Wayne.' With superior craftsmanship, we have successfully expanded our reach to over 100 countries, including prominent markets such as the United States, Germany, Indonesia, Canada, Australia, and Russia, along with extensive penetration across Southeast Asia. This extraordinary global footprint affirms our standing as a preeminent international leader in our field.
Our unwavering mission is to deliver service excellence that surpasses the expectations of our esteemed clientele. Whether your needs call for ready-to-go solutions or bespoke configurations, we specialize in providing finely-tuned solutions tailored to your unique specifications. Every component in our cutting-edge machines is meticulously handpicked from world-renowned suppliers and industry trailblazers in machine control, ensuring not only exceptional performance but also unparalleled reliability. Our machines seamlessly integrate across a myriad of industries and artistic ventures, from woodwork, detailed metal and stone crafting, aluminum fabrication, and boat building to shop fitting and precision mold making. Backed by a dedicated and highly skilled after-sales service department, an adept sales team, and rigorous quality assurance protocols, you can purchase with unshakable confidence. We extend a warm invitation to customers and prospective business partners across the globe to join us in mutually rewarding collaborations. By offering exceptional service, impeccable quality, and competitive pricing, Wayne stands as the quintessential choice. We enthusiastically anticipate forging partnerships with you to create substantial value. Reach out with your requirements, and let's engage in a productive dialogue. We eagerly await your contact, poised to embark on a promising journey together.
FAQ
1. Is it all right to make customer's own brand name?
A: yes. we are available with OEM
2. Are you a manufactuer or trading company?
A:We are the manufacturer with Laser machine and CNC lathe machine
3. Can you do the design for us?
A: yes. if you want a different control system design or higher column , we are available.
4 . What is your terms of delivery?
A: FOB Qingdao.
5. What's your payment term?
A: T/T OR L/C at sight.

---
