China Hose Very Cost-Effective SAE 100 R12 3/8′ 1/2′ 5/8′ 3/4′ 1′ 1-1/4′ 1-1/2′ 2′ No Middle Man

Product Description

SANYEFLEX Reliable Hydraulic Hose ManufacturerProduct Description SAE 100 R12
INNER TUBE: oil-resistant synthetic rubber
REINFORCEMENT: four spirals of high-tensile steel wire
COVER: abrasion and weather-resistant synthetic rubber
TEMPERATURE RANGE: -4ºC to +100ºC
Product Parameters

HOSE ID		Wire OD		Hose OD	Working Pressure		Burst Pressure		Minimum Bend Radius	Weight
Inch	mm	Min(mm)	Max(mm)	mm	MPa	Psi	MPa	Psi	mm	kg/m
3/8	9.5	16.9	18	21.1	31	4500	124	18000	127	0.70
1/2	12.7	19.4	21	24.3	28	4500	110	16000	178	0.83
3/4	19	26.6	28.2	31.9	21	3000	83	12000	241	1.30
1	25.4	34.5	36.1	40.5	21	3000	83	12000	305	1.70
1 1/4	31.8	43.3	45.6	50.7	17	2500	69	10000	419	3.08
1 1/2	38.1	49.6	52	58.7	14	2000	55	8000	508	4.30
2	50.8	63.9	66.2	73	14	2000	55	8000	660	5.63

Wrapped Surface Hydraulic Hose Smooth Surface Hydraulic Hose Application
Company ProfileHebei Sanye Fluid Technology Co., Ltd. is a China-US cooperative enterprise. SANYEFLEX has strong financial strength and technical strengths. Our factory occupies a total area of 110,000 square meters, with a plant area of 70,000 square meters and a total investment of 65 million yuan. Our company has been deeply involved in the hydraulic hose industry for nearly 20 years. We have two technical research and development teams, and more than 40 on-the-job engineers are respectively dedicated to technical research in the field of hydraulic fluids and the development of refrigeration systems.
Our company specializes in the production of mid-high-end hydraulic hose series products, such as steel wire braided hose (American standard, German standard), steel wire spiral hose (American standard, German standard), metal hose, air pipe, and joints, and other products. With excellent product quality, perfect after-sales service, and reasonable prices, we gradually increase the market share of our products. Our products are widely used in mining, metallurgy, petroleum, construction machinery, and chemical industry, and are exported to more than 30 countries and regions such as the United Kingdom, the United States, Germany, South America, and Russia. The company adheres to the core values of "integrity-based, customer first". Unswervingly promote the development concept of "leading by originality, developing talents, rooting in leanness, and bravely climbing the peak". Carry out technical R&D and manufacturing closely around customer needs, provide first-class services to a broad audience, and strive to become an industry leader.Factory tourPackaging & Shipping
Why Choose SANYEFLEX?Specialized in hydraulic hose production research and development for 20 years, has rich experience and technology.Imported raw materials directly from the United States, Japan, and South Korea.Automatic mixer workshop.Using an intelligent production line fully automated transfer process.Each hose will pass strict inspection before delivery.Reliable product quality and high safety performance, reducing the cost of the enterprise.FAQQ1:Can you do OEM?
A: Yes, we can do OEM products. Welcome!
Q2: Are you a factory or trading company?
A: Factory! We are a 100% manufacturer, and we have 20 years of experience in hydraulic rubber hose production. Welcome to visit our factory.
Q3: Is a free sample available?
A: Yes, free samples are available, customers only pay the freight cost.
Q4: How about your delivery time?
A: Within 20 days after you do the payment.
Q5: What are your terms of packing?
A: Generally in rolls well wrapped with colorful poly stripes or as your requirement.
Q6: What are your terms of payment?
A: Payment<= 1000 USD, 100% in advance. Payment>= 1000 USD, 30% T/T in advance, balance before shipment.
For more detailed information, please feel free to contact us!

---
