High Efficiency CE Standard Garage Rolling Shutter Door Octagonal Pipe Roll Forming MachineHigh Efficiency CE Standard Garage Rolling Shutter Door Octagonal Pipe Roll Forming MachineHigh Efficiency CE Standard Garage Rolling Shutter Door Octagonal Pipe Roll Forming Machine
| Machine Specifications |
| Weight | About 5.4tons |
| Size | About 6.1M*1.3M*1.2M(length x width x height) |
| Color | Main color: bule or as your need |
| Warning color: yellow |
| Suitable Raw Material |
| Material | GI PPGI GL PPGL |
| Thickness | 0.3-0.8mm |
| Yield Strength | 235Mpa or as your need |
| Main Technical Parameters |
| Quantity of forming rollers stations | 15 |
| Diameter of forming rollers shafts | 70mm |
| Roll Forming Speed | 15m/min |
| Forming rollers material | 45# steel, coated with chromed treatment |
| Cutter material | Cr12MOV, with quenched treatment |
| Controlling system | PLC |
| Electric Power requirement | Main motor power: 5.5kw |
| Hydraulic unit motor power: 4kw |
| Electric voltage | According to customer's requirement |
