High Speed Pet Stretch Pet Bottle Blow Blowing Equipment

US$4,000.00-50,000.00 1 Set (MOQ)

Basic Info.

Model NO.
8-cavity 16000-18000bph
Raw Material
PET
Making Method of Parison
Extrusion-Blow Molding
Automation
Automatic
Computerized
Computerized
Certification
CE, ISO9001:2008
After-sales Service
for Year Service
Advantage 1
Strong Frame with Handle More Strong
Suit Product
PP or Pet Bottle
Guarantee
One Year
Delivery Time
30-60day
Model Type
Auto or Semi-Auto Type
Transport Package
Wooden Case
Specification
SB
Trademark
tango
Origin
Zhangjiagang
HS Code
8422301090
Production Capacity
30 Sets Per Month

Product Description

Product description:
UNIT RYSB-C06
90/8
Number of cavities 8
Clamping force Kn
Max.heating power Kw 48
Operation pressure Kg/cm2 8
Max.blowing pressure Kg/cm2 30
Theoretical output bph 8000 (500ml)
Max.container volume ltr 1.5
Max.inlet outer diameter mm 42
Max.product ovter diameter mm 90
Max.product height mm 320
Weight t 5.5
Size(L*W*H) mm 6100*2000*2000.
6100+2000

Blowing machine main configuration
Product Name Origin Brand
(PLC)
computer touch screen		 China Inovance

Ration servo motor		 China Inovance

Variable pitch servo motor		 China Inovance

Clamping servo motor		 China Inovance

Stretch Servo Motor		 China Inovance

Oven servo motor		 China Inovance

Servo reducer		 Taiwan Liming

Servo reducer		 Taiwan Liming

magnetic switch
Taiwan		 Yuan Lifu

Low voltage electrical appliances		 German Siemens

Photoelectric switch
Japan		 Omron

Throttle valve
Taiwan		 AirTAC

Blow valve
Italy		 Norgren

Action valve
Korea		 ARK

Lift cylinder
Taiwan		 AirTAC

Manipulator Pneumatic Finger		 German FEST-O

Sealing cylinder		 Taiwan Lingde

SCREW AIR COMPRESSOR+BOOSTER
item
unit
parameter		 remarks
model EMS-10/40W
Working Medium air
compression
screw and piston
cooling mode Primary water cooling Two-stage water cooling
driving mode Direct transmission Two-stage belt drive
compression stage 3 1 stage 1
2,3 stage 2 3
flow m3/min 10
discharge pressure MPa 4.0 gauge pressure
suction temperature ºC ≤40
exhaust temperature ºC ≤50 after cooling
motor power KW 120
Circulating water flow
 T/h 50T
temperature range 10ºC 32 ºC 5ºCTemperature difference of 5 ºC
10less than 10ºC Pay attention to anti-freezing measures
,inlet and outlet diameter DN40
High pressure exhaust pipe interface
 DN40
weight Kg 5000 per set
Voltage 380V/50Hz
motor IP IP54

Mold
