| 20ft ISO Tank Container | ||
| Frame Dimensions (L x W x H) | 6058 x 2438 x 2591 mm | |
| Nominal Capacity | 20000-25000 litre (±0.75%) | |
| Maximum Gross Mass | 36000 kgs | |
| Tare Mass | 3550 kg (± 3%) | |
| Design Temperature (Frame & Tank) | -40 to +130 °C | |
| Pressure | Working | 4.0 bar |
| Test | 6.0 bar | |
| Material | Tank (Shell & Ends) | 316L/SAN50028-7/WNr 1.4402/1.4404 |
| Frame | SPA-H or equivalent | |
| Steam Heating | 6 runs, 110mm width stainless steel 304 | |
| Manhole | 500 low TIR provision, 8 point fixing with super tanktyt Lid seal | |
| Safety Relief | 2½" BSP Supermaxi Highflow relive, without gauze, Pressure only set at +4.4 bar (63.8psi). | |
| Air Inlet Assembly | 1.5 BSP air inlet with 1 1/2BSP connection, | |
| Bottom Discharge | 3 stainless steel foot-valve with butterfly valve and blank flange / 3 BSP cap and chain. | |
| Top Discharge | Provision only | |
| Approval | Lloyds or BV Construction Certificate, IMDG, CFR49, ADR/RID, AAR 600, CSC, TC, TIR, ISO UIC, US/UK DOT | |
