Convenient Water Cooled Cbb61 Generator Capacitor

Product Description

Convenient water cooled cbb61 generator capacitor
Capacitor 50uf 250vac CBB65 capacitor for air conditioning is mainly used for washing machine, air conditioner, air conditioner, refrigerator, freezer, dishwasher, dryer and other household appliances, single phase motor, UPS power supply system, etc. The main features include good self-healing performance and stable performance.Shock resistance current, high overload capacity, long service life, low loss, high insulation resistance.In addition, the capacitor has built-in explosion-proof device with high safety. At the same time, it can be equipped with built-in or external inductance to make up the capacitive inductance module.
Features
1)Very small dissipation factor, small internal temperature rise.
2)High insolation resistance.
3)Good capacitance stability.
4)Excellent self-healing property.
5)Anti-shock current, large overload capacity.
6)Small volume, light weight.
7)Equipped with a pressure explosion-proof apparatus for safe and reliable usage.

Technical Parameter
Ambient Temperature	Rated Voltage(VAC)
-40ºC~85ºC	150~500
Range of Capacitance(uF)	Operating Frequency
2~100	50/60Hz
Testing Voltage(VAC)	Dissipation Factor
T-T: 2Un/2S T-C: ≥2200VAC/2S	tan δ ≤ 0.002 (100Hz)

Outline Size
Capacitance (uF)	240V~300V		350V~400V		440V~450V
	D (mm)	H (mm)	D (mm)	H (mm)	D (mm)	H (mm)
5	40	55	40	55	40	55
7.5	40	55	40	65	40	65
10	40	55	40	55	40	65
12.5	40	55	40	65	40	75
15	40	55	40	65	40	75
17.5	40	65	40	75	40	75
20	40	75	45	75	50	65
25	40	75	45	85	50	75
30	45	75	50	75	50	85
35	45	75	50	75	50	85
40	45	85	50	85	50	100
45	45	100	50	100	50	110
50	45	100	50	100	50	110
55	50	90	50	110	50	125
60	50	100	50	125	50	125
65	50	110	50	125	55	110
70	50	125	55	110	55	125
80	50	125	55	125	60	125
100	55	125	60	125	60	140

Other types besides the above listed can be produced according to customer's needs. Data above may be changed without notice. Executing Standards: IEC60252, UL810, EN60252, VDE0560-8, GB/T3667.1-2005. Capacitance Tolerance: ± 5% or fulfilled upon request.

---
