Palm Oil Disc Centrifuge Separation Machine From Shenzhou

Product Description

Type: palm kernel oil refining
Processing material: palm kernel
Capacity: 30-1500T/D
Major Equipment: degumming tank, heat exchanger, decolorization tower, deodorization tower
Application: High efficiency oil refining method applicable for crude palm kernel oil, coconut oil
3 phase disc stack separator is a high-speed, stable, sealed, efficient, and automatic slag discharge 3 phase separation equipment. It is widely used for liquid, liquid, solid 3-phase separation or liquid-liquid separation. The 2-phase solid-liquid separation disc separator has only one liquid discharge port and one slag discharge port, while the 3-phase disc separator has two liquid discharge ports and one slag discharge port, which can separate two liquids with different specific gravity at the same time. It can also discharge solid phase materials. Compared with the 3 phase decanter centrifuge, the 3 phase disc separator has larger rotation speed and G force. The 3 phase decanter centrifuge usually has a separation factor of about 3000G, while the 3 phase disc stack separator G force is up to 12000G. Therefore, the 3 phase disc separator can more thoroughly separate liquids with different specific gravity and the liquid phase discharged is more clarified. However, compared to 3 phase decanter centrifuges, 3 phase disc separator is more used to separate materials containing fine particles, with less solids content. So before entering the 3 phase disc separator, the material can separated by the decanter centrifuge for pre-stage separation to reduce the solids content and remove big particles.
Palm Kernel Oil Refining Process Flow Chart:
The separated material enters into the heart of the machine, that is, the inside of the bowl. Under the action of strong centrifugal force, the material passes through a set of disc bundle separation intervals. With the neutral holes of the disc as the interface, the liquid with larger specific gravity moves along the disc wall towards the outside the neutral hole, where heavy slag accumulates in the sediment area, and the heavy phase liquid flows upward to the centripetal pump; the lighter liquid with a smaller specific gravity moves along the disc wall into the neutral hole and converges to the lower centrifugal pump. The light and heavy liquid phases are discharged by the lower centrifugal pump and the upper centripetal pump respectively; the heavy slag is regularly discharged; continuous production is implemented. Technical Paramter of palm oil disc separator

Model	Bowl Speed (rpm)	Capacity (Hour/L)	Running Load (Watts)	Dimensions, Overall (mm)
				Width	Front-to-Back	Height
DHY/DHYC250	11100	500-800	4.0	850	850	1200
DHY/DHYC270	7300	1000	4.0	950	950	1200
DHY/DHYC300	7150	1500	5.5	1025	1300	1300
DHY/DHYC360	7056	2000-3000	7.5	1500	1100	1500
DHY/DHYC400	7038	3000	7.5	1500	1100	1550
DHY/DHYC500	6600	5000-8000	15.5	1772	1500	1855
DHY/DHYC550	6200	8000-15000	18.5	1970	1560	1970
DHY/DHYC730	4900	50000-80000	55.0	2580	1980	2340

Main process of the Palm kernel oil refinery plant:
Crude Palm kernel oil degumming process:Physical oil refining is applicable because of low gum content inside palm kernel oil.
Crude Palm kernel oil deacidification/neutralization process:Gas supported heat-conducting oil boiler and packed tower make high vacuum deacidification from crude palm kernel oil.
Crude Palm kernel oil decoloring/bleaching process:Whit clay makes continuously decolorization of crude palm kernel oil, and enters into filter for filtration.
Crude Palm kernel oil deodorization/distillation (deodorising unit) process
Crude Palm kernel fractionation process

Palm kernel oil refinery plant featured advantages:
Palm kernel oil refining processing line adopts advanced and scientific physical refining and totally stainless steel tank refining. Palm kernel oil is non-drying oil with low gum content, which is suitable for physical refinery. Fatty acid composes of 45%-51% lauric acid and 13%-25% cardamom acid. Palm kernel oil contains soap grade and food grade.The process of Palm kernel oil refinery is to refine the crude edible oil, to remove gossypol, protein, phospholipid, grume, moisture and other impurities, in order to reach the purchase of food and storage.The process of palm kernel oil refinery includes mechanical refinery method, chemical refinery method and physical refinery process refinery process

Palm Oil Mill Plant Advantages: Self-sufficient palm oil production, low production cost, low environmental pollution, recycling utilization of resource.
Palm oil mill plant adopts the most scientific palm oil processing equipment configuration, using mechanical oil pressing technology, make successfully extraction of palm oil from palm fruit.
Palm oil milling process plant covers three major plants of crude palm oil pressing plant, water treatment plant and power supply plant.
The entire palm oil process is totally environmental protective, low energy consumption, and low production cost.

---
