Milling and Beveling Machine Gd-20-16mn

US$20,000.00 1 Set (MOQ)

Basic Info.

Model NO.
GD-20-16Mn
Structure
Bed type
Milling Cutter Type
Angle Milling Cutter
Milling Cutter Structure
Indexable Type
Controlling Mode
Artificial
Automatic Grade
Automatic
Precision
High Precision
Certification
CE
Condition
New
The Example of The Steel Plate
16mn
The Max Groove Width(mm)
20mm
The Beveling Angle
25°-55°
The Min Strainght Edge(mm)
2mm
The Max Thickness(mm)
45
Voltage
380V-3pH-50Hz(Other Voltage Can Customized)
Transport Package
Standard
Specification
Standard
Trademark
DATANG
Origin
China
Production Capacity
10 Sets Per Month

Product Description

The beveling machine is adopted with the milling principle to mill the angle for tje edge of the steel plate,and to get the groove for welding .The machine is accurate in size,bright and smooth in surface,and is formed once.There is no need to make de-burring.It's convenient in operation,very high in working efficiency(three meters per minute)and low in energy consumotion.
Easy Operate
The beveling machine is adopted with the milling principle to mill the angle for the edge of the steel plate, and to get the groove for welding. The machine is accurate in size, bright and smooth in surface and is formed once. There is no need to make DE-burring .
Model GD-20
The example of the steel plate Q235 16Mn 1Gr18N19Ti
The max groove width(mm) 20mm 16mm 12mm
The beveling angle 25°~55°
The min strainght edge(mm) 2mm
The max thickness(mm) 45mm
Voltage 380V-3PH-50HZ(OTHER VOLTAGE CAN CUSTOMIZED)
