Dk7740f High Speed CNC Wire Cutting EDM Machine

Product Description

Product Description
Servo Motor CNC Electroerosive Wire Cut Machine (Advanced) DK7740F is our state-of-the-art wire cutting machine. With its exceptional cutting accuracy and consistency, this machine is perfect for precision work piece processing and precision die processing.
At Jilin Songjiang Tech-trade Co., Ltd., we take pride in delivering top-notch equipment that meets the highest standards. Our CNC EDM Electroerosive Machine DK7740F is no exception. With its advanced features and cutting-edge technology, it's a game-changer in the industry.
Product Parameters

Equipment Specification

No.	Description	Unit	Specification
1	Model		DK7740F (Advanced)
2	Worktable Size (L×W)	mm	570×800
3	Worktable Travel (X×Y)	mm	400×500
4	Max. Workpiece Height	mm	250
5	Max. Workpiece Weight	kg	400
6	Machine Dimensions (L×W×H)	mm	1850×1420×2100
7	Machine Weight	kg	1900

Electrical Parameters

No.	Description	Unit	Specification
1	Max. cutting speed	mm²/min	200
2	Wire electrode diameter	mm	Φ0.10~Φ0.25
3	Machining precision (Cutting the octagon in 10mm)	mm	≤0.010/10mm
4	Taper/Workpiece height		*60°/80mm
5	Power consumption	kw	3
6	Surface roughness	μm	Single cut Ra<2.0, **Multiple cut Ra<0.8
7	High pressure water tank		Multi-stage filter system
8	Wire guided spinneret		Ruby spinneret
9	Control method of wire spool, cooling system		Controlled by the program and the NC panel
10	Repeating position precision of X, Y-axis	μm	±1
11	Guide rail type		Linear guide rail
12	Speed regulation of transport wire tube		Converter
13	Number of control axes		5
14	Power Supply		AC380V, 50Hz

Detailed Photos
Packaging & Shipping
