Klt-Dmt-Ar0234 V3.0 IR850pb WiFi Camera 2.3MP Ar0234 Global Shutter Mipi Interface 850-1100nm IR Pass Auto Focus Camera Module

Product Description

2.3MP AR0234 Global Shutter MIPI Interface 850-1100nm IR Pass Auto Focus Camera Module
Camera Module No. KLT-DMT-AR0234 V3.0 IR850PB

Camera Module No.	KLT-DMT-AR0234 V3.0 IR850PB
Resolution	2.3MP
Image Sensor	AR0234 Global Shutter
Sensor Type	1/2.6"
Pixel Size	3.0 um x 3.0 um
EFL	6.03 mm
F.NO	2.10
Pixel	1920 x 1200
View Angle	68.0°(DFOV) 57.0°(HFOV) 35.0°(VFOV)
Lens Dimensions	18.00 x 18.00 x 23.99 mm
Module Size	60.00 x 26.00 mm
Module Type	Auto Focus
Interface	MIPI
Auto Focus VCM Driver IC	DW9714P
Lens Model	KLT-LENS-TRC-20522A18-01
Lens Type	850nm-1100nm IR Pass
Operating Temperature	-30°C to +70°C
Mating Connector	AXT524124
