Mobile Telescopic Stacker Portable Radial Stacking Conveyor

Product Description

Product Description Mobile radial stacker telescopic belt conveyor for sale
Zoomry Stacker Conveyors are purpose built for each application and offer unique operational features to allow luffing, slewing and telescoping action as required. From Design to produce, we offer one-station services. According to the field use needs of material yard, open-pit mine, wharf and concentrator, the equipment can realize flexible movement and stacking. By rotating the stacking material in the sector area and the stretching characteristic of the blanking point, the stacking material can reach 30,000-50,000 tons.
Specification

Product name	Manufacturer mobile telestack for bulk material handling system
Material	Carbon steel
Belt width	800mm-1600mm or per customer's reques
Max Capacity	450t/h-2400t/h or per customer's request
Certification	ISO9001:2008,GB,DIN,ISO,CEMA,JIS
Application	Mining, Port, Cement, Steel, Metallurgy, Electric Power, Coal, Machinery and Other Industries
Advantages	Portable, rotatable, height adjustable, conveying length retractable, radial movement

Application Advantages

Type	Width (mm)	Max Capacity (m³/h)	Speed (m/s)	Length (m)	Max inclined angle(°)	Telescopic length (m)
ZR80SF	800	450	2.5	40	20°	10-15
ZR100SF	1000	700	2.5	40	20°	10-15
ZR120SF	1200	1000	2.5	50	20°	15-20
ZR140SF	1400	1500	2.5	50	20°	15-20
ZR160SF	1600	2400	2.5	55	20°	15-20

1. Rotating the stacker fan-shaped and increase the stacker capacity;
2. The length is able to further increased the stacking capacity;
3. it can be moved as a whole, easy for users to change the place of use
4. through the expansion and contraction of the hydraulic cylinder, the stacker angle adjustable, can reduce the dust and easy tomove and maintenance at the same time
5. Non-standard design of length and transportation capacity according to users' needs;
Packaging & Shipping What Type of Stacker We Have? Certifications

---
