PVC Bottle Extrusion Blow Moulding Machine (BM-A4)

Product Description

PVC Bottle Extrusion Blow Moulding Machine
1. We are manufacturer
2. Our machine obtain CE, ISO9000
3. Small bottle pp, pe, pv
PVC bottle extrusion blow moulding machine blow molding machine, extrusion blow molding machine
Applied material: HDPE, PP, PE, PVC, PA etc.
Production capacity: 7L (max)
Machine Screw: 75mm.

Unit	Item	Specification	Description
Extruding system	Screw diameter	Φ75mm	Mixing model
	Max. Product Volume	6L	Double station and single die-head
	Screw L/D	24:1
	Material of screw and barrel		38CrMoALA
	Plasticizing capacity	90KG/Hr	Based on HDPE 5502
	Extruding method		Inverter motor, hardness tooth surface gear box
	Driving power	30KW
	Screw revolution	10_90rpm
	Heating zones	3	Temperature module from Mitsubishi PLC
	Heating power	10KW	Solid state (SSR) and plug connection for all heaters
	Blowers	3
	Cooling function	Yes	Cooling water for feeding zone and gear box
Clamping unit	Structure	Large arm and joint operation type clamping unit with large and uniform clamping force	Adopt linear guide way ensure high speed and precious, strong clamping force
	Idle cycle time	pc/h≈240/300
	Platen dimension	390*460mm	W×H
	Platen distance	150-500mm	Min.~Max.
	Clamping force	75KN
	Mold thickness scope	150-300mm
	Mold moving stroke	Induce switch + moving	Adopt linear guide way
	Clamping stroke	Stroke switch + moving	Adopt linear guide way

---
