Jewelry machinery and equipment, 3 motors CNC machine

Product Details

Product Details

Product Description

Product Description
Name:Xiongxing Gemstone Cutting Surface CNC Machine (Rough Grinding+Fine Grinding+Polishing)
No. 810501888 Model XX-380D
Steps to use.
Menu→Gemstone type selection→Select round→Parameter view and modify the parameters of the top surface→Grinding parameters of the first layer of parameters open→Operation mode open→Select the start→Y1 parameter selection rules batch input→Input the number of board bits 8→Confirm the batch input
1 engineer can operate 2 machines
Parameters
Model: XX-380D
Rated voltage: AC 220V/380V
Spindle speed: 2800 r/min
Output power: 250W
Appearance size: 80*76*150cm
Processing size: 3-50mm
Number of preserved forms: 120
Shapes: round, oval, square, rectangle, triangle, pear, heart, teardrop, horse's eye. Other customized shapes, etc.
Processing time: 2 minutes/1 piece
English language: switchable
Diameter of loaded grinding disk: 6 inches 150mm
Equipment weight: 150kg

CNC type faceting machine processing sequence:
Pre-type out of the embryo: cutting → shaping → blank punching → blank → follow-up to do angle
Embryo→glue stone→ring type→frontal facet grinding→frontal facet polishing→turning and gluing gemstone→backside grinding→backside polishing→removing glue and cleaning
CNC faceting machine configuration:
Cutting machine → shaping machine → CNC faceting machine
