Basic Info.
Application
Double Beam Crane, Gantry Crane, Bridge Crane, Tower Crane, Single Grinder Crane, Lifting Platform, Small Crane
Maximum Lifting Height
>20m
Certification
ISO9001:2000
Packaging Details
Carton and Pallet
Supply Ability
10000 Sets Per Yea
Transport Package
Wooden Case
Production Capacity
50000 Units Per Year
Product Description
characteristic:
There are two types of monorail trains: manually operated monorail trains and manually operated monorail trains. The manually operated monorail train is driven by a bracelet, while the manually operated monorail train is driven by lifting heavy objects and can freely walk on the lower flange of the I-beam rail. The distance between the wheel flange can be adjusted according to the width requirements of the I-beam rail. The manual hoist can be hung under the train to form a manual lifting and transportation trolley, which can be used in various lifting machinery and equipment industries.
Hand pulled trolley is a type of lifting machinery that is structurally simple, easy to operate, lightweight, and suitable for transportation. It can be paired with chain hoists, electric hoists, and other lifting products to form a lifting and transportation trolley. It can run freely on the lower flange of an I-beam track with a certain curvature radius, and is used for transporting goods, equipment, etc.
model
| load(T)
| test load(T)
| Specification(mm)
| IRecommended beams
| net weight(kg)
|
A
| B
| C
| H
|
0.5
| 0.5
| 0.75
| 208
| 172
| 190
| 108.5
| 75-125
| 5.5
|
1
| 1
| 1.5
| 220
| 206
| 222
| 122
| 75-125
| 8
|
1.5
| 1.5
| 2.25
| 260
| 231
| 238.5
| 130
| 100-150
| 13
|
2
| 2
| 3
| 260
| 240
| 267
| 132.5
| 100-150
| 14
|
3
| 3
| 4.5
| 285
| 279
| 319
| 181
| 100-150
| 21
|
5
| 5
| 7.5
| 338
| 318
| 384
| 219
| 125-175
| 35
|
10
| 10
| 15
| 362
| 380
| 490
| 275
| 125-180
| 66
|
>>
