Small capacity LPG storage tank
LPG small tank is a fixed pressure vessel with single-layer tank structure. It is specially used to store liquefied petroleum gas. It adopts low-alloy steel plate for container, which has excellent performance, safety and reliability. It is equipped with safety accessories and loading and unloading accessories matched with liquid unloading gun of tank truck with pump.
DESCRIPTION
Certifications
What certifications do we own?
We have professional design and manufacturing qualifications of Chinese A2, A3, C2, SAD and American ASME U/ U2
Main functions
Key Features
The main materials are low alloy steel plates for containers, valve accessories, preferably international well-known brands, professional design and manufacturing team, perfect quality assurance system, and the conventional volume series covers 0.5m ³~ 15m ³， It can be customized according to customer needs. In addition, it can be equipped with tank load monitoring system + vehicle tank reading device according to customer needs, and can provide operation platform construction services according to customer needs to realize remote information monitoring and vertex distribution algorithm support.
What is the purpose of the product?
This product is a special small storage tank for storing liquefied petroleum gas. It is mostly used in civil or commercial LPG distribution scenarios in rural areas, schools, residential areas and other places.
What benefits will you get from product?
Customers can safely store liquefied petroleum gas by using this product, and can receive liquid unloaded by tank truck with pump in non gas station.
Use
Where can this product be used?
This product can be used in areas with ambient temperature of - 40 ℃ ~ 50 ℃, and in civil or commercial LPG distribution modes in rural areas, schools, residential areas and other places.
Who might use this product?
LPG gas companies or operating enterprises are potential customers of this product.
Use range
Suitable for mixed liquefied petroleum gas, propane, commercial propane or commercial propane butane mixture medium with saturated vapor pressure ≤1.60MPa at 50℃
Some common uses of the product?
Fixed point delivery.
Advantages
Primary advantages
Safe and reliable, low price and high quality.
Why should I buy this product?
Forty years of professional design and manufacturing experience, the first market share in China for thirty-six consecutive years, reliable quality and service guarantee.
What makes this product different to competitor products?
High cost performance, quality assurance, high responsibility and perfect after-sales service system.
Our service
Our Policy
HONGTU has the design & fabrication capacity of LPG stationary storage tanks including above-ground tanks, underground tanks and mounded tanks etc. All kinds of tanks could be customized according to the customers' requirements.
Unique deliveries
EXW/FOB/CFR/CIF/DAP
Shipped by container vessel
Warranty information
One year warranty after delivery
Payment method
-What payment method do we have?
T/T,L/C
Export cases
Main markets
Asia, Southeast Asia, Africa, South America, North America
Specifications
Product specifications
Technical parameters
Horizontal Household LPG Storage Tank
|
Water Capacity
| Outsie Diameter
| Overall Length
| Overall Height
| Tank Empty Weight (Approx.)
|
570L (150 US GAL)
| 761mm
| 1426 mm
| 920 mm
| 190 kg
|
950L (250 US GAL)
| 761mm
| 2286 mm
| 920 mm
| 265 kg
|
1000L (265 US GAL)
| 761mm
| 2400 mm
| 920 mm
| 280 kg
|
1890L (500 US GAL)
| 1065 mm
| 2380 mm
| 1224 mm
| 510 kg
|
3785L (1000 US GAL)
| 1115 mm
| 4185 mm
| 1275 mm
| 925 kg
|
4730L (1250 US GAL)
| 1115 mm
| 5175 mm
| 1275 mm
| 1130 kg
|
DESIGN PARAMETERS
|
Design Pressure
| 1.724 Mpa (250 Psig)
| Corossion Allowance
| 0 mm
|
Design Temperature
| 51.7℃(-125°F)
| MDMT
| -29℃(-20°F)
|
Filling Medium
| LPG
| Filling Ratio
| 0.85
|
Shell & Head Material
| SA-516 GR.70 (As-rolled)
| Forging Material
| SA-105(Normalized)
|
Hydro./gas leak test pressure
| 2.25/1.724 MPa(325/250Psig)
|
Mounting Type
| Aboveground and Horizontal
|
Tank Surface Painting
| The dry film thickness is 185um
|
Standard and Code
| According to ASME BPVC, Section VIII, Div. 1. 2017 edition
|
Valves and Fittings for Chose
| Full set of valves & fittings are available, e.g. safety valve, liquid withdrawal, level indicator, multivalve, filter valve, draining pipe, etc.International famous brands such as REGO, MEC, CAVAGNA, WIKA, Rochester etc. are available, CIMC Hongtu has long and reliable cooperation relationship with these giant cooperation, competitive price will be offered.
|
Note: Above parameters are only for references, CIMC Hongtu can customize the products as per your different requirements. This table only shows main parameters of above-ground household LPG storage tank, CIMC Hongtu also supplies UNDERGROUND household LPG storage tank.
|
Components
Package included
Nude Packing
Accessories or Parts
N/A.
>>
