Rated 200kw 250kVA Continuous 180kw Natural Gas Generator Set with CHP Cogenerator

Product Description

Silent Rated 200kw Continuous 180kw Natural Gas Generator Set With CHP Cogenerator
Multiple units been installed in Europe and have run over than 10,000hours.
GENERAL INTRODUCTION ON SEVENPOWER COGENERATOR SET
-Powered by SINOTRUK engine
-Air-cooled type alternator
-Engine heat exchanger
-Exhaust heat exchanger made from full stainless steel,longer service life
-Integrated control cabinet
-Safe gas train
-Gas engine control system
-Auto lambda control,easy start
-All necessary engine protections, oil pressure, coolant temperature, over current, over voltage, overload, engine speed, frequency protection, battery voltage
-Easy control system, all information easily read from the controller screen, power output,voltage,current,power factor, engine speed,oil pressure,coolant temperature,battery voltage,run hours,start numbers,alarms,historical records

Main Specifications

Model Name	SP200N
Frequency (Hz)	50
Voltage	400/230
Fuel Type	Natural gas
Continuous Power(KWe)	200kw
Thermal Output	294kw
Electrical efficiency	33.8%
Thermal efficiency	49.7%
Overall efficiency	83.5%
Engine	SINOTRUK
Alternator	Kwise, other brands is available on request
Controller	ComAp
Canopy	With or without
Genset Gas Inlet Pressure	4-15kpa
Gas consumption@100% load	0.3m3/kW.h

For more information about the natural gas cogenerator 200kw, please consult with your sales representative.Thanks.
