Product Details
Product Description
Product Description
Product Description
Basic Info.
Model NO.
TM-IR5825
out-Feed
1.05 Meter
Total Tubes
18 PCS
Structure
Conveyor Oven
Each Oven Length
2 Meter
Belt Width
1 Meter
in-Feed
0.75 Meter
Belt Type
Teflon Belt
Dryer Width
1.25 Meter
Dryer Length
5.8 Meter
Transport Package
Plywood
Specification
CE
Trademark
Tamprinter
Origin
Shenzhen, Guangdong, China(Mainland)
HS Code
8443911900
Production Capacity
50sets/Month
Product Description
TM-IR5825 Economical Crafts screen printing infrared drying oven
Parameter:
| Parameter | Power/Specification | Remarks |
| Dryer Length | 5.8 Meter |
|
| Dryer Width | 1.25 Meter |
|
| Belt Width | 1 Meter |
|
| Belt Type | Teflon Belt |
|
| In-feed | 0.75 Meter |
|
| Out-feed | 1.05 Meter | 4 cooling fans on exit |
| Total Oven | 2 Pcs |
|
| Total Oven Length | 4 Meter |
|
| Each Oven Length | 2 Meter | 9 Tubes/ Oven |
| Total Tubes | 18 Pcs |
|
| Tube Type | Ceramic |
|
| Tube Power | 1000 W each |
|
| Working Power | 3 Phase- 380V/50Hz |
|
| Belt Motor Power | 90W- 5IK90RGU-CF | Brand- OTG/VTV- 220V/50Hz AC |
| Contactor | 90 Amp- 2 Sets | Brand- Chint/Delixi |
| Temp Range | 0- 250 Degree C |
|
| Temp Tolerance | +/- 5 Degree C |
|
Feature
1. Intelligent temperature control system, easy operation, can control of temperature deviation effective.
2. Adopt hot circulating system, save energy effectively.
3. Teflon screen belt , customers' designs are welcome
4. Far infrared heating pipe is especially suitable for solidifying heat-set and special type of printing ink.
5. Adjustable belt speed and tunnel temperature controls.
Packaging details
Standard export packing, major products using export plywood case packing, small products use thick carton packing, ensure that the product packaging integrity and safety;
Shipping methods
1. Shipping by sea(recommend big product or a lot of goods of the order)
2. By air
3. By express: TNT, EMS, DHL, Fedex, UPS etc
Common Remarks:
All Belt rollers/ belt adjustable rollers should be with best grade nickel
Each machine should have one MCCB inside of control panel
Each machine Belt Speed Control should be stable, noise free belt transmission
Each oven should be controlled by individual Temperature Control Unit
FAQ
1. Q:Are you a factory or a trading company?
A:we are factory manufacture of printing machine and we provide perfect OEM and after-sale service.
2. Q:Can you send me the video to show how the machine works?
A:certainly,we have made video of every machine and uploaded them to Youtube.
3. Q:How can I know your machine works well?
A:Before delivery,we shall test the machine working condition for you.
4. Q:How can I know your machine is designed for my product?
A:You can send us samples of your product and we test it on machine.
Model No-TM-IR 7825
| Parameter | Power/Specification | Remarks |
| Dryer Length | 7.8 Meter |
|
| Dryer Width | 1.25 Meter |
|
| Belt Width | 1 Meter |
|
| Belt Type | Teflon Belt |
|
| In-feed | 0.75 Meter |
|
| Out-feed | 1.05 Meter | 4 cooling fans on exit |
| Total Oven | 3 Pcs |
|
| Total Oven Length | 6 Meter |
|
| Each Oven Length | 2 Meter | 10 Tubes/ Oven |
| Total Tubes | 30 Pcs |
|
| Tube Type | Ceramic |
|
| Tube Power | 1000 W each |
|
| Working Power | 3 Phase- 380V/50Hz |
|
| Belt Motor Power | 120W- 5IK120RGU-CF | Brand- OTG/VTV- 220V/50Hz AC |
| Contactor | 90 Amp- 3 Sets | Brand- Chint/Delixi |
| Temp Range | 0- 250 Degree C |
|
| Temp Tolerance | +/- 5 Degree C |
|
CONVEYOR DRYER MODELS
| Model No | Unit Price
Set |
| 5825 | 3600USD |
| 5845 | 3733USD |
| 6625 | 4133USD |
| 6645 | 4267USD |
| 7825 | 4933USD |
| 7845 | 5067USD |
>>
