| Negotiable | 1 Piece (MOQ) |
| Model | RTX220 | |
| Specification | ||
| Machine working weight | kg | 21500 |
| Bucket capacity | m3 | 0.5-1.28 |
| Boom length | mm | 5700 |
| Stick length | mm | 2900 |
| Performance | ||
| Swing speed | rpm | 12.4 |
| Walking speed | km/h | 3.1-4.5 |
| Bucket digging force | KN | 136.2 |
| Stick excavator | KN | 97 |
| Engine model | / | USA IMPORT |
| Rated power | kw/rpm | 110/1950 |
| Cooling method | / | water cooling |
| Body size | ||
| Total length of transport | mm | 9510 |
| Overall width of transport | mm | 2900 |
| Overall height of transport | mm | 3030 |
| Boarding width | mm | 3000 |
| Track length | mm | 4440 |
| Track full width | mm | 2990 |
| Track shoe width | mm | 600 |
| Back end turning radius | mm | 2750 |
| Minimum ground clearance | mm | 480 |
| Scope of work | ||
| Maximum excavation range | mm | 9910 |
| The largest excavation range on the ground | mm | 9735 |
| Maximum excatation depth | mm | 6445 |
| Maximum excatator height | mm | 6045 |
| Maximum discharge height | mm | 6810 |
| Maximum vertical depth that can be excavated | mm | 6045 |
