| US$990.00-1,180.00 | 3 Sets (MOQ) |
| Specification | |
| Model No. | KY500/KY800 |
| Swing over bed | 420mm |
| Distance between centers | 500mm/800mm |
| Max.longitudinal travel | 440mm/740mm |
| Max.cross travel | 200mm |
| Taper of spindle | M.T.4 |
| Spindle hole | 28mm |
| Step of speed/Range of speed | 7/160-1360r.p.m |
| Barrel travel | 70mm |
| Taper of center | M.T.3 |
| Metric thread can be cut | 0.2-6mm |
| Inch thread can be cut | 4-120 T.P.I |
| Longitudinal range of automatic feeding | 0.05-0.35mm |
| Cross range of automatic feeding | 0.05-0.35mm |
| Drilling/Milling | |
| Drilling capacity | 22mm |
| Table size(L*W) | 475*160mm |
| End mill capacity | 28mm |
| Face mill capacity | 80mm |
| Distance between spindle center and column | 285mm |
| Distance between spindle nose and table | 306mm |
| Spindle travel | 110mm |
| Spindle taper | M.T.3 |
| Range of spindle speed | 120-3000r.p.m |
| Swivel angle of headstock | ±180° |
| Main motor power/Drill and mill mait motor | 0.55kw/0.55kw |
| Standard accessories | |
| Drilling chuck | 1 pc |
| Toolbox & tools | 1 set |
| Optional accessories | |
| 4-jaw chuck | 1 set |
| Backplate | 1 pc |
| Follow rest | 1 pc |
| Steady rest | 1 pc |
| Face plate | 1pc |
| Collet chuck | 1 set |
| Turning tools | 1 pc |
| Leadscrew cover | 1 set |
