| MODELS | CK6156B |
| CAPACITY | |
| Max.swing over bed | Ф560mm |
| Max swing over carriage | Ф330mm |
| Width of bed | 405mm |
| Max. length of workpiece | 750/1000/1500/2000/3000mm |
| Max turning length | 650/900/1400/1900/2900mm |
| 6-way turret max turning diameter | Ф390mm |
| 6-position tool post max turning length | 490/740/1240/1740/2740mm |
| TRAVEL | |
| Max.cross travel(X) | 320mm |
| Max.longitudinal travel (Z) | 650/900/1400/1900/2900mm |
| FEED | |
| Rapid feed for axis X | 8m/min |
| Rapid feed for axis Z | 10m/min |
| SPINDLE | |
| Spindle nose | A2-8 |
| Spindle bore | Ф80mm |
| Taper bore of spindle | M.T.NO.7 |
| Steps of spindle speed (manual) | 2 steps (variable within each step) |
| Range of spindle speed | 50~400rpm, 400~1600rpm |
| TOOL POST | |
| Tool post stations | 4, 6 or 8-ways |
| Tool cross section | 32×32mm |
| TAILSTOCK | |
| External diameter of tailstock sleeve | Ф75mm |
| Taper bore of tailstock sleeve | M.T.NO.5 |
| Max.traverl of tailstock sleeve | 150mm |
| OTHERS | |
| Min. input | 0.001mm |
| Main motor power | 7.5kw |
| Coolant pump power | 90w |
| Overall dimensions(L×W×H) | 2250/2500/3000/3500/4500×1200×1550mm |
| Net weight | 2800/3100/3600/4100/4700kg |
