Insulation Sheet Making Machine

US$85,000.00 1 Piece (MOQ)

Basic Info.

Condition

New

Customized

Automatic Grade

Automatic

Structure

Horizontal

Type

Rubber Extruder

Model Number

Bne150-01-00

Screw Diameter

150mm

Color

Based on Customer Demand

Dimension(L*W*H)

4200(L)×1600 (W)×1500(H)mm

Weight

6500kgs

Power

160kw

L/D

20:1

Vacuum System

Yes

Screw Speed

0-45

Gear Reducer

18.5:1

Capacity

1000kg/Hour

Place of Origin

Zhejiang, China (Mainland)

Transport Package

Wooden Pallet

Specification

150mm

Trademark

ZHEJIANG BAINA

Origin

Taizhou

HS Code

8477209000

Production Capacity

10 Set/Sets Per Month

Product Description

Rubber extrusion vulcanization machine for insulation sheet and pipe product, yoga mat, rubber foam product.

Various types of basic parameters:

Item	Diameter of screw(mm)	L/D ratio	Speed of screw(r/min)	Driving power(kw)	Max output of production (kg/h)	Weight(kg)
150mm 20D (vacuum)	150	20: 1	0-45	160	1000	6500
150mm 16D	150	16: 1	0-45	132	800	6500
120mm 20D (vacuum)	120	20: 1	0-50	110	700	5200
120mm 16D	120	16: 1	0-50	110	600	5200
90mm 20D (vacuum)	90	20: 1	0-55	55	320	3200
90mm 16D	90	16: 1	0-55	55	280	3200
75mm 20D (vacuum)	75	20: 1	0-55	37	160	1200
75mm 16D	75	16: 1	0-55	37	140	1200
50mm 12D	50	12: 1	2-70	7.5	50	600

Order Guide:
1. Ship date: 30----120 working days
2. Payment terms: T/T or L/C
3. Full range of devices to be provided on schedule, as per client demands.
4. Responsible for training technicians and operators for operation and maintenance of the equipment.
5. Responsible for installing and debugging all devices.
6. Formula available and long term technical supports.
7. Guarantee: One year guaranteed repair and lifelong tracking service, with parts provided.
8. All the parameters of the machine on metric units and in English.
9. Package: Standard export wooden pallet.
