2880mm Cylinder Type Production Line for Carton Paper Making Machine

Product Description

High Strength 2880mm Cylinder Type Production Line for Testliner Carton Paper Making Machine

Product Description
I. Technial Parameters of High Strength 2880mm Cylinder Type Production Line for Testliner Carton Paper Making Machine:

Raw materials	recycled paper, wood pulp
Output paper	corrugated paper,craft paper, carton paper, flutting paper
Output paper weight	90-200g/m2
Capacity	80T/day
Fourdrinier wire width	3350mm
Net paper width	2880mm
Working speed	150-200m/min
Designing speed	250m/min
Rail gauge	4000mm
Drive way	Alternating current frequency converter speed control, sectional drive.

II Main Frame of High Strength 2880mm Cylinder Type Production Line for Testliner Carton Paper Making Machine:

Cylinder part of high production 2880mm 50tpd corrugated board production line, fluting paper making machine: 1500mmx 3450mm stainless-steel plate cylinder, 3pcs;450mm×3450mm couch roll,3pcs,rubber hardness HS-38ºC±2, 500mm×3450mm reverse roll 1pcs; rubber hardness HS-86ºC±2,pneumatic loaded device,multitube for pulp,stainless

Squeeze part: 400mm×3550mm squeeze roll,2 pcs, rubber hardness HS-90ºC±2, pneumatic loaded device

Pre-press part: 650mm×3450mm top roll,one pcs of natural marble stone roll; Φ600mm×3450mm bottom roll, one pcs of rubber roll; rubber hardness HS-95ºC±2, pneumatic loaded device

Press part :850mm×3450mm, 2 pcs of natural marble stone rolls ; 800mm×3450mm rubber roll,2pcs; rubber hardness HS-97ºC±2, pneumatic loaded device

Pre-sales services for High Strength 2880mm Cylinder Type Production Line for Testliner Carton Paper Making Machine:
1) Offering comprehensive technical and business consultation services;
2) Proposing the most suitable scheme and equipment for our clients;
3) Designing and fabricating targeted products according to the special requirements of clients;
4) Training periodically high qualified service technician.
5) Offering professional technical consultation services.
6) Adopting all-around computer aided design (CAD) to design the whole production line.
8) Providing all-around turn-key projects as follows: production design,equipment manufacture, installation and adjustment, technical service, conforming product.
9) Complete sets machine will be pre-installed and tested to confirm that the machine are in good condition before delivery.
10) On time delivery.

After-sales service for High Strength 2880mm Cylinder Type Production Line for Testliner Carton Paper Making Machine:

1) Highly inspecting equipments in every working procedure, quality comes first;
2) Fast & Safe Delivery;
3) Assisting our clients for foundation construction of equipments;
4) Dispatching engineers to install and debug equipments;
5) Training the first-line operators on site;
6) Regularly visit clients to solve production problems;
7) Providing life-long maintenance service;
8) Providing technical exchanging;
9) One year guarantee time after the machine run well;
10) Supply you spare parts at a competitive price for a long time.

Company Information Zhengzhou Dingchen Machinery Co., Ltd is a professional paper machine manufacturer integrated with scientific research, design, manufacturing, installation and commission. Focused on R&D and production, the company has over 30 years' experience in paper machinery and pulping equipment production. The company has a professional technical team and advanced production equipment, with over 150 employees and covering an area of 45, 000 square meters.
The company's leading products include various types of high speed and capacity test liner paper, kraft paper, carton box paper machine, cultural paper machine and tissue paper machine, pulping equipment and accessories, which are widely used in the production of packaging paper for various items, printing paper, writing paper, high grade household paper, napkin paper and facial tissue paper etc.
Based on high quality products and service, the company has been recognized by overseas customers and markets, its products has been exported to Pakistan, Uzbekistan, Turkmenistan, Bangladesh, Cambodia, Bhutan, Israel, Georgia, Armenia, Afghanistan, Egypt, Nigeria, Kenya,
Burkina Faso, Sierra Leone, Cameroon, Angola, Algeria, El Salvador, Brazil, Paraguay, Colombia, Guatemala, Fiji, Ukraine and Russia etc.

Packaging & Shipping
Our Services

FAQ

---
