Reliable CE Certified Hand Chain Hoist for Safe Lifting Solutions

Product Description

Product Description
0.5T to 30T Hand Chain Hoist
CORE FEATURES:
Technical Specifications
0.5T-30T SWL capacity range with 4:1 safety factor
T80-grade high-tensile chains (DIN 5685 compliant)
Structural Excellence
Lightweight steel framework with 8mm reinforced alloy housing
Precision helical gears achieving 92%+ mechanical efficiency
Safety Engineering
ASME B30.10 certified drop-forged hooks (200% safety margin)
EN 13157:2020 validated 400% static & 150% dynamic load testing
Surface Protection
Anti-corrosion electrostatic powder coating (100+μm thickness)
Certification & Support
CE Marked & GS Certified with full Declaration of Conformity
12-month warranty + lifetime technical support
PRODUCT DETAILS
TECHNICAL PARAMETER

HSZ-E CHAIN BLOCKS 0.5 Ton -30 Ton
Model	HSZ-0.5E	HSZ-1E	HSZ-1.5E	HSZ-2E	HSZ-3E	HSZ-5E	HSZ-10E	HSZ-20E	HSZ-30E
Rated load (T)	0.5	1	1.5	2	3	5	10	20	30
Standard litt(m)	2.5	2.5	2.5	2.5	3	3	3	3	3
Test load (T)	0.75	1.5	2.25	3	4.5	7.5	12.5	25	37.5
Efforts required at capacity (N)	262	314	343	318	347	382	390	390	394
Diameler of load chain(mm)	6	6	8	6	8	10	10	10	10
No.of load chains	1	1	1	2	2	2	4	8	12
Dimenslons (mm)A B C D	142 126 280 28	142 126 300 32	178 142 360 38	142 126 380 40	178 142 470 44	210 165 600 50	358 165 730 64	580 195 1000 82	688 394 1050 82
Net weight (kg)	9.5	10.5	17.5	14.5	23	35	68	155	233
Extra welght per meter of extra liftt(kg)	1.7	1.7	2.4	2.5	3.7	5.3	9.7	19.4	28.3

Main Product
Company Profile
Established in 1986, Changshu Seagull Crane&Hoist Machinery Co., Ltd. is a leading manu-facturer of lifting tools and equipments, including hand chain hoists, lever hoists, electric hoists, lifting clamps and more. With ISO9001:2015certification and TUV CE/GS approvals, we ensure top-quality products for global markets like the USA, Germany, Japan, and others. As a trusted OEM partner for international brands, we export 95% of our products worldwide. Our advanced testing facilities and strict quality control guarantee reliable performance. Over 50% of our clients have collaborated with us for more than 10 years, thanks to our consistent quality and excellent service.
SEAGULL is your reliable partner for innovative lifting solutions.
Our Advantages
Certificate&Exhibition
Packaging & Shipping
FAQ
About US
Q1 Manufacturer or Trading Company?
We are Manufacturer and trading company, based in ChangshuCity,Jiangsu Province. Focus: high-quality, safe lifting solutions.
Q2 Certifications?
ISO9001, CE, GS, ASME compliant. Certificates available upon request.
Q3 OEM/ODM?
Yes. Custom colors, logos, manuals,packaging.
Q4 Advantages?
Quality products, wide range, customization, competitive pricing, excellent after-sales service.
Products
Q1 Main Products?
Manual Chain Hoists, Electric Hoists, Electric Trolleys, Beam Trolleys, Beam Clamps, Lifting Clamps, Snatch Blocks, Permanent Magnet Lifters, Mechanical Jacks, Manual Winches, Webbing Slings, etc.
Q2 Manual Chain Hoist Capacity?
0.25 tons - 50 tons. Custom options available.
Q3 Chain Material?
High-strength alloy steel, heat-treated, EN818-7 compliant.
Q4 Electric Hoist Voltage/Control?
220V/380V/415V/440V,50Hz/60Hz. Hand & remote control options.
Q5 Choosing the Right Tool?
Consider load, height, environment, frequency, safety. Contact sales for assistance.
Q6 Product Catalog?
Request via contact form.
Orders&Payment
Q1 MOQ?
Varies. Different products with different MOQ. Please contact us for details.
Q2 Payment Methods?
T/T or L/C in USD/RMB/EUR.
Q3 Delivery Time?
30-60 days, but negotiable for urgent order.
Q4 Trade Terms?
FOB, CIF, CFR, negotiable
After-Sales Service
Q1 Warranty?
1 or 2 years warranty depends on different products, against defects (non-human caused).
Q2 After-Sales Support?
Contact sales representative, email
Q3 Technical Support?
Installation, debugging, maintenance assistance available.
Other
Q1 Samples?
Available on request. Fees may apply.
Q2 Become an Agent?
Contact sales team for details.

---
