Most Popular Concrete Mixing Plant Yhm90 Concrete Batching Plant Free Foundation Concrete Mixing Station Price

Product Description

Product Description
Most Popular concrete mixing plant YHM90 concrete batching plant Free foundation concrete mixing station price
1.No Foundation Mixing Station
The production of concrete without foundation mixing plantcan avoid the need for foundation, and the installation is relativelysimple. More importantly, the overal performance is relativelygood and more environmentally friendly.
Excellent performance, equipped with automatic controlsystems,material mixing systems, weighing systems, etc, more suitablefor use in projects such as highway bridges and hydropower projects.Convenient transportation and quick entry into the workingenvironment.
Convenient disassembly and assembly, meeting the needs ofhigh-frequency engineering projects, saving time and costs.
The program has a high-end image and is easy to operate and learn.Effectively adjust relevant control parameters; Can view the production data storage related to the equipment and print it in various report forms at any time; The selection of control systems is diverse and can be equipped with multiple languages.

Model		YHM40	YHM60	YHM90	YHM120	YHM180
Theoretical Productivity		40m3/h	60m3/h	90m3/h	120m3/h	180m3/h
Mixer nominal capacity		800L	1200L	1500L	2000L	3000L
Aggregate Bin Volume		2/3/4x6m3	2/3/4x8m3	2/3/4x8m3	2/3/4x15m3	2/3/4x20m3
Measuring range	Aggregate	2000kg±2%	2000kg±2%	3000kg±2%	4000kg±2%	6000kg±2%
	Powder	300kg±1%	400kg±1%	800kg±1%	1200kg±1%	1500kg±1%
	Water	200kg±1%	300kg±1%	500kg±1%	600kg±1%	800kg±1%
	Admixture		50kg±1%	50kg±1%	50kg±1%	50kg±1%
controller		Fully Automatic	Fully Automatic Computer	Fully Automatic Computer	Fully Automatic Computer	Fully Automatic Computer
Total power(Excluding accessory equipment)		55kw	65kw	85kw	200kw	240kw
Discharge height		3.8m	3.8m	3.8m	4.2m	4.2m

2.Standard Mixing Plant
HZS Series Concrete Batching Plant adopts thedesign conceptof large platform and modularization,the overall structure is compact and aesthetic.With features of high equipment configuration,reasonable structure and accurate weighing, Thisplantis mainly used in the medium & high marketsas commercialconcrete and large constructionprojects etc.

Number Name	Model
	HZS240	HZS180	HZS120	HZS90	HZS60
Theoretical Productivity	240m3/h	180m3/h	120m3/h	90m3/h	60m3/h
Mixer model	MAO6000/4000	MAO4500/3000	JS2000	JS1500	JS1000
Mixing electric power	2X75kw	2X55KW	2X37KW	2X30KW	2X18.5kw
Mixing cycle	60s	60s	60s	60s	60s
Mixer nominal capacity	4000L	3000L	2000L	1500L	5000L
Maximum particle size of aggregate	≤φ80mm	≤φ80mm	≤φ80mm	≤φ80mm	≤φ80mm
Belt conveyor productivity	1200t/h	800t/h	650t/h	650t/h	500t/h
Discharge height	4.2m	4.2m	4.2m	4.2m	4.2m
Total power of the entire station	≈400kw	≈300kw	≈260kw	≈210kw	≈160kw
Aggregate weighing range and accuracy	±2%	±2%	±2%	±2%	±2%
Cement weighing range and accuracy	±1%	±1%	±1%	±1%	±1%
Weighing range and accuracy of fly ash	±1%	±1%	±1%	±1%	±1%
Water weighing range and accuracy	±1%	±1%	±1%	±1%	±1%
Admixture weighing range and accuracy	±1%	±1%	±1%	±1%	±1%

3.YBS Mobile mixing plant
This series of mobile concrete mixing plant integrates mobility mixing,
environmental protection,energy conservation,and foundation free functions,making
easy to operate time and labor saving, and economicaand practical.
Equipped with a fully automatic control system, with low requirements for operators

Model		YBS-30	YBS-40	YBS-60	YBS-90	YBS-120
Theoretical Productivity		30m³/h	40m³/h	60m³/h	90m³/h	120m³/h
Mixer		JS500	JS750	JS1000	JS1500	JS2000
Aggregate Bin Volume		2x6m³	2x6m³	2x10m³	2x10m³	4x10m³
Measuring range	Aggregate	1000Kg±2%	1000Kg±2%	2000Kg±2%	3000Kg±2%	4000Kg±2%
	Powder	300Kg±1%	300Kg±1%	400Kg±1%	800Kg±1%	1200Kg±1%
	Water	200Kg±1%	300Kg±1%	300Kg±1%	400Kg±1%	600Kg±1%
	Admixture	50Kg±1%	50Kg±1%	50Kg±1%	50Kg±1%	60Kg±1%
control system		Fully Automatic Computer	Fully Automatic Computer	Fully Automatic Computer	Fully Automatic Computer	Fully Automatic Computer
Total capacity		35kw	45kw	55kw	80kw	110kw
Dragging speed per hour		≤40km/h	≤40km/h	≤40km/h	≤40km/h	≤40km/h

4.YC Mobile Mixing Station YZ-CX Series Mobile Concrete Batching Plant adopts a self-contained structure, the batching machine and the feeding belt as well as the mixer are concentrated on one chassis. The batching machine can be weighed separately by 2/3/4 bins side by side.This mobile concrete batching plant can be supported by the hydraulic supporting legs when producing, during the whole process, it can be completed theproduction without any installation; it is very convenient to hoist on the truck when moving. The mixing station can be directly towed by a forklift.

Model		YC-30	YC-40	YC-60	YC-90	YC-120
Theoretical Productivity		30m3/h	40m3/h	60m3/h	90m3/h	120m3/h
Mixer nominal capacity		500L	750L	1000L	1500L	2000L
Aggregate Bin Volume		2x5m3	2x5m3	3x6m3	3x8m3	4x15m3
Measuringrange	Aggregate	1000kg±2%	1000kg±2%	2000kg±2%	2000kg±2%	3000kg±2%
	Powder	300kg±1%	400kg±1%	500kg±1%	800kg±1%	1200kg±1%
	Water	200kg±1%	300kg±1%	400kg±1%	400kg±1%	600kg±1%
	Admixture			50kg±1%	50kg±1%	50kg±1%
control system		Fully Automatic	Fully Automatic	Fully Automatic	Fully Automatic Computer	Fully Automatic Computer
Total power		30kw	45kw	55kw	80kw	115kw
Dragging speed per hour		≤40kw/h	≤40kw/h	≤40kw/h	≤40kw/h	≤40kw/h

5.Pulling bucket mixing station
Mixing host adopts JS series forced twin shaft mixer, good mixing quality and high efficiency. Modular structure, small footprint, easy dismantle, low investment, high eficiency, simple and low cost maintenanceOur plant use computer control, it can be switched between automatic control and manual control, easy to operation and master.Aggregate,cement,water,liquid additive of the ingredients are measured by electronic scales, high precision ingredients. Use the bucket to lift the aggregate, lifting motoris cone motor, sufficient power and durable.

Complete machine part	Model	HZS75	HZS50	HZS35	HZS25
	Complete machine part(m³/h)	75	50	35	25
	Discharge height(m)	4	3.8	3.8	3.8
	Working cycle time(s)	75	75	75	75
	Total installed power(kw)	90	60	50	40
Mixer section	Model	JS1500	JS1000	JS750	JS500
Mixer section	Model	PLD2400	PLD1600	PLD1200	PLD800
Weighing system	Dinas weighing accuracy	+2%	+2%	+2%	+2%
	Cement weighing accuracy	+1%	+1%	+1%	+1%
	Water weighing accuracy	+1%	+1%	+1%	+1%

Packaging & Shipping
Packing and Shipping CONTAINER: Put the machine into container, Maybe need disassemble, cheapest freight and fast shipping ; Factory Photos
Company Profile
Founded in 2006, HENAN ULIKE INDUSTRY Co., Ltd. is a top package equipment solution provider in China, especially for construction machinery parts and so onWe Ulike industry are always committed to offer our customers high quality products with reliable performance, competitive price and comprehensive services, to ensure every engineering project to be run smoothly on schedule. With over Fifteen years' experience in the field of Commercial Vehicle, Engineering Machinery, construction machinery, agricultural machinery and accompanying to fulfill strictly ISO 9001: 2008 standard, we had established and have been consistently keeping good business relationship with many general contractors, civil engineering firms and construction companies throughout the world. We Ulike industry participated as package equipment provider previously include airport projects in Africa, power plant projects in Middle East, dredging projects in South America, highway projects in Oceania, rural and municipal road projects in Southeast Asia, and we are still achieving more and more projects at present. To provide reliable products with quick delivery time, to make prompt reaction for spare parts and after-sales services, to visit the users field regularly for local training and maintenance, Ulike industry has been often praised by our customers and has taken great reputation as a trustworthy project partner. Ulike Inductry believe in combining our own achievement together with our customer benefits. Open communication, effective planning and elaborative preparation always commit us to execute and deliver our promises for our customers all over the world.
After Sales Service

Before-Sale	After-Sale
1. Airport pickup, Booking hotel.	1. Visiting the famous scenic spots in zhengzhou.
2. Visiting our company yard, Enjoying Free test drive.	2. 1-Year warranty for All the equipments
3. Different machines to compare with each other.	3. A lifetime of parts and technical support.
4. Interpreting mechanical configuration information in detailed.	4. Fast parts deliver and quick reply for any feedback .

FAQ
1. How many days it need to install the concrete plant?
Our team have suficient experience to install the plant,as usual,we only need 7-15 days to finsh it.
2. Why should I choose your concrete plant?
We are a professional manufacturer of concrete plant for more than 20 years,we attended many national projects and the customers are satisfied with our quality.
3. What are your payment terms?
T/T, L/C, Western Union, Moneygram, Paypal or other.
4. Do you have CE and ISO9001 certification?
Yes,all of our product have passed CE and ISO9001 certification.
5. How long is your product warranty?
Our warranty period is one year.

---
