Woodworking Machinery 1000mm Width Belt Solid Wood Door Cabinet MDF Plywood Automatic Brush Polish Sanding Calibrating Polishing Sander Machine for Wooden

Product Description

Main Features
1. The micro-computer front control panel can be operated conveniently and quickly.
2. The feed speed is controlled by the frequency converter, which can be operated flexibly and conveniently.
3. The frame has high strength, large weight and nice stability.
4. The maintenance is convenient, safety performance is excellent, and the failure rate is low. 5. The sanding unit adopts the cast structure with slight deformation and excellent damping performance.
6.High-strength motor and top brand bearing ensure best performance.

Model	ST-RP1300
Max. processing width	1300mm
Sanding thickness	3-110mm
Processing panel length	≥500mm
Sanding belt size	1320*2200mm
First sanding motor power	37kw
Second sanding motor power	22kw
Convey motor power	4kw
Feeding speed	30-60m/mim
Lifting motor power	0.37kw
Total motor capacity	63.55kw
Diameter for first roller	190mm
Diameter for second roller	190mm
Working air pressure	0.6Mpa
Machine dimension	2090*2600*2100mm
Weight	3000kg

Sand rack
The front sand frame is the adjustable steel roller and the rear sand frame is the combined structure of the rubber roller mat, which is suitable for the constant thickness sand and fine polishing of various panels.

Conveyor belt
Working table for the thickened marble, conveyor belt for five layers of rubber materials,Not afraid of rain, not afraid of sun, long service life.
Motor
Sanding machine adopts copper core motor, stable and durable long service life.

Power system
Configure to increase the highspeed motor to improve work efficiency




Shandong Guandiao CNC Equipment Co., Ltd is an innovative enterprise engaged in research and development,production, sales and good after- sales service. The company's main products include Panel furniture CNC cutting machine, Woodworking CNC Machining Center, CNC router , Multi-head cylinder CNC engraving machine, Styrofoam CNC router, 3D scanner, Vacuum membrane press machine, Vacuum forming machine, Laser engraving and cutting machine, etc. Products applied to the panel furniture, European furniture, solid wood furniture, advertising, stone, building decoration, handicrafts, mold making, staircases column, PCB printing, automotive industry, packaging industry, shipbuilding, wood manufacturing, watches and clocks, accessories, seals and other industries.After nearly 10 years of development, the company has a perfect technical team, clear labor division, ensuring the high quality products sent to the whole country, to the world.
1. Delivery and Lead time:
Machine will be proper packed and loaded in container, as multiple loaded to save space or wooden carton sealed for better transportation.
2.Warranty:
Machine warranty is 12 months. Machine as normal using and maintenance condition, if get any problem, will provide spare parts for free. Out of warranty, will collect the accessories cost. Technical support for maintenance or fix on time and all the time.
3. Technical support:
Manual and video illustration of the machine will be provided 24 hours online by Ali Trademanager, Skype, Email, QQ, or telephone24 hours online by Ali Trademanager, Skype, Email, QQ, or telephone Technical support by email, whatsapp, wechat,imo and skype available on time.
4.After sale service:
Normally the machine will sent on whole except the machine is over size to load container. so the machine arrange in production immediately after get electricity (air and water some model needed).

5.We accept the ODM,OEM If you have other needs, please let me know

---
