Steel Wire Mesh Industrial Stackable Storage Cage

Product Description

steel wire mesh industrial stackable storage cage
Introduction:

Product Description	Brand	YD
	Type	wire mesh container
	Product code	HBE-MC-Wire mesh container
	Dim.Ext(L*W*H)	1030X840X850mm
	Dim.Int(L*W*H)	950X760X700mm
	Mesh size	50x50mm
	Wire guage	6.0mm
	Weight	51.5kg
	Loading Capacity	1300KG
	Stackability	3 levels
	Finishing	Zinc plated/ Hot dip galvanized/Powder coating
	Quantity/40HQ	470 sets
	Product warranty	1 year for wire mesh container
	Product shelf life	up to 3 or 5 years against proper handling
	MOQ	50 sets
	Scale	Heavy Duty
	Application	widely used in agricultural,electronic equipment

All Dimensions

Model	External Size(mm)	Inner Size (mm)W*D*H	Wire diameter (mm)	Grid (mm)	loading capacity (kgs)	loading quantity
						20GP	40GP	40HQ
A-1	800*600*640	750*570*500	6.0	50*50	700	280	550	660
A-2			6.0	50*100	600
A-3			5.0	50*50	500
A-4			5.0	50*100	500
B-1	1000*800*840	950*770*700	6.0	50*50	1200	220	440	550
B-2			6.0	50*100	800
B-6			5.0	50*50	600
B-7			5.0	50*100	500
C-1	1200*1000*890	1150*970*750	6.0	50*50	1500	152	300	380
C-2			6.0	50*100	1000
C-6			5.0	50*50	1000
C-7			5.0	50*100	800
F-1	1200*800*840	1150*770*700	6.0	50*100	600	152	300	380
F-2	1200*800*890	1150*770*750	6.0	50*50	1000	152	300	380
D-1	800*500*540	750*470*400	6.0	50*50	600	280	550	660
D-1			6.0	50*100	400
D-3			5.0	50*50	400
D-4			5.0	25*25	800

Features:
Open wire mesh provides excellent visibility for easy inventory control.
Wire mesh storage cages help eliminate dust and dirt build up.
These one piece heavy-duty folding containers feature wire mesh arc-welded to a channel formed steel base.
The sides and corners of these shipping containers are heavily reinforced.
Notched, positive stacking legs permit handling by forklift or pallet truck.
Drop gate allows access when stacked.
Durable powder coating or zinc plating finish resists rust and corrosion.
Wire bulk containers stack up to 4 high.
Quote Information
Please offer us the following information in details, so we can give you the exact quotation:
1)Full details of size:L*W*H(mm)
2)Loading capacity
3)Surface treatment
4)Order Quantity
5)Quote: You need FOB(Shanghai) or CIF(Destination Port).
6).Delivery Time: Whether urgency.

---
