Digital Gaussian Meter GS-100DAH
Applications:
Used for measuring the magnetic induction intensity of DC magnetic field, AC magnetic field, radiation magnetic field, remanence magnetic field, earth magnetic field, and other magnetic fields.
Features:
* Portable, wide range.
* Easy to operate, clear LIQUID crystal display.
* There are measurement/peak retention, mT/Gs unit conversion.
* 200mT/2000mT range conversion, etc.
Details:
Measuring range:0~200mT~2000mT(20kGs)
Frequency range:1-400HZ
The accuracy of:
DC,1%/AC,1%,1-400HZ (measured in a uniform magnetic field)
Resolution:
DC×1:0.00~200.00mT 0.01mT
DC×10:0.0~2000.00mT 0.1mT
AC×1:0.00~200.00mT 0.01mT
AC×10:0.0~2000.00mT 0.1mT
Magnetic field under test:
Dc magnetic field (static magnetic field)
Ac magnetic field (dynamic magnetic field)
Functional specifications:
Peak retention Gs(Gauss) /mT (Millitesla) can be switched freely
Dc polarity of measurement:
N for positive, S for negative
Operating Conditions:5℃~40℃
Relative humidity:20%~80%(There is no dew)
Power supply:
4x1.5v AAA (UM-4) Battery
Overall dimensions:140mm (L) X73mm (W) X 30mm (H)
Instrument weight:180g
Display mode:41/2LCD
According to the unit:mT/Gs
Standard Accessories:
Main engine (one)
Hall sensor (one)
Operating Instructions (one copy)
GUANGZHOU LANDTEK INSTRUMENT CO LTD is the real professional manufacturer of meters and instruments in China.
To Lisa Li
Email / Skype: lisali0428@outlook.com
For more details,please feel free to contact Lisa.Thank you!
>>
