Automatic Rubber Tyre Vulcanizing Press, Bearing Curing Press Machine

Product Description

Automatic Rubber Tyre Vulcanizing Press, Bearing Curing Press Machine Product Description 1.Product Description

This series plate vulcanizing machine special-purpose takes shape the equipment for the rubber profession.Heats up the way to uses the electric heating(steam or oil heats up),the power uses the height combination to pump for the oil way, reduces the equipment the power loss.
The electrical control uses the advanced PLC control technology,may realize automatic controls when, automatically operates the mold,is automatic warm controls and so on the craft.And may realize automatically deflates. Thus guarantee product quality and high efficiency.
May have custom-made each kind of four columns,the frame type, the work table emigration-ton type,the work table emigration type in addition according to the customer product technological requirement and so on the many kinds of plates vulcanizing machine Automatic Rubber Tyre Vulcanizing Press, Bearing Curing Press Machine Detailed Photos
Solid Tyre Rubber Molding Press, Rubber Hydraulic Curing, Door Mat Vulcanizing Machine Automatic Rubber Tyre Vulcanizing Press, Bearing Curing Press Machine
2. Usage of 2023 Hot Rubber Bridge Bearing Vulcanizing Press ,Rings Gasket Molding Press Machine Rubber/Plastic vulcanizing press machine, Prepreg glass fiber hydraulic press, Composite carbon fiber heating vulcanizer press is mainly applied to vulcanize large rubber products and volume production of rubber products. It is also named Rubber mat vulcanizing press, rubber molding machine, rubber vulcanizing machine, rubber vulcanizer, rubber vulcanizing press, rubber moding press, hydraulic press, hot press, etc. 3. Features of 2023 Hot Rubber Bridge Bearing Vulcanizing Press ,Rings Gasket Molding Press Machine 1.This press with PLC control, high production efficiency.
2. The presses heating method with steam heating or electrical heating we can as our clients required to design.
3. Press with automatic warning device, high safety and convenient.
4. The machines used for rubber vulcanization are known as rubber vulcanizing machines.
5. This rubber vulcanizing machine strengthens raw rubber by chemically treating it and make rubber harder and stronger.
This vulcanization machine is extremely useful for testing strength of rubber and find applications in numerous industries. Product Parameters 4. Technical parameter of Rubber/Plastic vulcanizing press machine, Prepreg glass fiber hydraulic press, Composite carbon fiber heating vulcanizer press
It is including deckle board,pedestal,hydraulic cylinder,plunger,moving platforms,top bridge,top and bottom hot plates and so on.

Type	XLB-DQ1200× 1200× 2	XLB-DQ1300× 2000× 1	XLB-Q1200× 2500× 1	XLB-Q1500× 2000× 1	XLB-Q2000× 3000× 1	XLB-Q1400× 5700× 1
Total Pressure(MN)	315t	560t	750t	1000t	1800t	2800t
Plate Size(mm)	1200× 1200	1300× 2000	1200× 2500	1500× 2500	2000× 3000	1400× 5700
Daylight (mm)	200	400	400	400	400	400
Layer NO.	2	1	1	1	1	1
Piston Stroke(mm)	400	400	400	400	400	400
Plate Unit Area Pressure	22	21.5	25	33.5	30	35
Main Motor Power(kw)	3	8	9.5	11	26	43.5
Overall Dimension(L× W× H) (mm)	1685× 1320× 2450	2000× 1860× 2500	2560× 1700× 2780	2810× 1550× 3325	2900× 3200× 2860	2400× 5800× 3600
Weight(kg)	9500	17000	20000	24000	66000	110000

Noted: OULIMACHINE CE ISO Approved Rubber hydraulic press machine, 1000Ton big frame hot heating curing press machine heating vulcanizer press heating press heating plates size and Clamping force , piston stroke can be customized by clients required.
OULI MACHINE CE ISO Approved Rubber hydraulic press machine, 1000Ton big frame hot heating curing press machine heating vulcanizer press heating press Electric heating hydraulic molding press machine, SBR,NBR mat vulcanizing press Configuration of Automatic PLC Rubber Vulcanizing Press, Frame Hydraulic Vulcanizer Press Machine, Column floor Mat/rings gasket Moulding Curing Press OULI MACHINE Frame plate: The material is made of Q235A steel plate with overall numerical control cutting, and the surface is sandblasted. OULI MACHINE Oil cylinder; The material of the oil cylinder is high quality QT500-7, ductile iron QT-500 is passivated after aging, or forging material is used, tensile strength ≥50kgf/mm The plunger is made of LG-P chilled alloy material, which has high surface hardness and is not easy to wear. The depth of the chilled layer is 8-15mm and the hardness is HRC 70 degrees, which improves the overall service life of the plunger. OULI MACHINE Extractor sliding table: The sliding surface is made of S50# steel, and has been heat-treated to a hardness of HRC 55-58. It has a long wear-resistant life and is equipped with a bearing design to make the entry and exit molds slide stably. OULI MACHINE Hydraulic system: The main hydraulic components adopt well-known brands such as Taiwan Qiyang, Beijing Huade, Japan Yuken, etc., easy to buy and replace, reasonable layout, and easy to maintain and repair. OULI MACHINE Electrical system: The main PLC electrical components of this machine adopt Mitsubishi's internationally well-known brands. The electrical device has the advantages of small size, compact structure, fatigue resistance, and is suitable for continuous high-strength work. Heat insulation board: The heat insulation board adopts high-quality calcium silicate board, with a pressure resistance of 3.5Mpa or more, and a heat insulation coefficient of 0.031
5.Manufacturing Technique
OULIMACHINE CE ISO Approved Rubber hydraulic press machine, 1000Ton big frame hot heating curing press machine
WHY CHOOSE OUR OULI MACHINE Of CE ISO Approved Rubber hydraulic press machine, 1000Ton big frame hot heating curing press machine
QINGDAO OULI MACHINE CO., LTD WORKSHOP SHPW OF CE ISO Approved Rubber hydraulic press machine, 1000Ton big frame hot heating curing press machine Company Profile 6. COMPANY INFORMATION---QINGDAO OULI MACHINE CO., LTD
Established in 1997, Qingdao Ouli Machine Co., Ltd. was located in Huangdao District, the west coast of Qingdao city, Shandong province, China. We are specialized in rubber machinery designing,manufacturing and maintenance work. OULI main products: 1. Rubber mixing equipment: kneader, bucket,mixing mill, bale cutter
2. Rubber vulcanizing machine: Four-column press, Frame press, E-type press, tire and tube press, Belt vulcanizing press.
3. Automatic and semi-automatic waste tire recycling equipment
4. Rubber calendaring machine: 2 roll, 3 roll, 4 roll calender, calendaring line
5. Rubber extruding equipment: Hot feed extruder,cold feed extruder, belt extrudingand calendering line .
6. Reclaimed rubber production line: XKJ-450 , XKJ-480 Rubber reining mill.
7. Paper roll cutting machine. Ouli machines have been exported to more than 20 countries such as America, Canada, Australia, Southeast Asia, Middle East,Brazil. We warmly welcome customers visit our factory and technology discussion is highly appreciated. Certifications 7. Certifications
OULI MACHINE COMPANY INTRODUCTION: QINGDAO OULI MACHINE CO., LTD Established in 1997 year, Located in qingdao city north of China. With more than 25 years development, OULI MACHINE more professional enterprise in design, Research and manufacturing rubber and plastic machines. OULI MACHINE main products: rubber banbury kneader mixer, two roll mixing mill, rubber calender, batch off cooling, rubber vulcanizing press, rubber extruder, tyre recycling line, and reclaimed rubber machines. OULI MACHINE company exported more than 100 countries in past 25 years, with CE, ISO and SGS certificates approved, And rich experience on guide machines' installation and maintenance after service.
