| Dimension | 160.0 x 84.0 x 17.5 mm |
| Weight | 287g(including battery) |
| Keypad | 1 Power key, 1 scan key, 2 volume key |
| Battery | 5100mAh rechargeable lithium polymer battery |
| Stand by time>300h | |
| Working time>12h(Depend on actual status and internet) | |
| Charging time: 3-4h | |
| Loudspeaker | Support |
| Vibrator | Support |
| Microphone | 2 mic, one for speaking, one for denoise |
| Display | 5.5inch(18:9) High Resolution IPS LTPS 1280*720 |
| Camera | 13MP camera |
| Touch panel | Corning Gorilla Glass(High durability) |
| Sensor | G-sensor, Range sensor, Light sensor, Vibrator |
| Indicator | Power, charging, status indicator |
| Card slot | 2 SIM card slot |
| Interface | Type-C |
| Structure | Bi-color injection molding |
| Performance parameter | |
| CPU | Octa-core ARM@CORTEX A53 MPcore 2.0 GHz |
| RAM+ROM | 4GB+64GB |
| Development environment | |
| O.S. | Android 9.0 rugged handheld pda |
| SDK | Qunsuo terminal development tool |
| P-Language | Java |
| Development tool | Eclipse/Android Studio |
| Operating environment | |
| Working temp. | -20 ºC~+50 ºC |
| Storage temp. | -40 ºC~+70 ºC |
| Humidity | 5%RH~95%RH(Non-condensing) |
| Drop test | Within operating range, 6 sides withstand 1.5 meter drop test |
| ESD protection | ±15 KV air discharge,±8 KV contact discharge |
| Rolling test | Rolling up to 1000 times 0.25 meters, 6 surface contact surfaces still running steadily after rolling, reaching IEC rolling standard |
| IP level | IP67(Meet IEC sealing standard) |
| Data communication | |
| WLAN | 2.4G/5G dual-band,Support 802.11 a/b/g/n/ac/,IPV4,IPV6; |
| WWAN | 2G: 850/900/1800/1900MHz |
| 3G: CDMA EVDO: BC0 | |
| WCDMA:850/900/1900/2100MHz | |
| 4G: B1/B3/B5/B7/B8/B20/B38/B39/B40/B41 | |
| Vo-LTE | Support Vo-LTE HD voice video call |
| BT | BT 5.0 |
| GNSS | Support GPS/Beidou/Glonass/AGPS |
| Barcode scanner | |
| Scanner engine | Zebra SE4710 |
| Scan pixels | 1280*800 |
| Decoding type | QR Code, Data Matrix, PDF417, Han letter code in line with international and domestic generic 1D code standards: UPC-A, UPC-E, EAN-8, EAN-13, ISBN, Code 128, GS1 128, IS BT 128, Code39, Code93, Code11, Interleaved 2 of 5, Industrial 2 of 5, Matrix25, Standard25, Code bar MSI/MSIPLESSEY, GS1 Data Bar, DPM, etc. |
| NFC/RFID | |
| Working frequency | 13.56MHZ |
| Communication | ISO14443A/B,ISO15693,NFC-IP1,NFC-IP2 and etc. |
| NFC standard | M1(S50,S70), CPU card, NFC tag and etc. |
