high capacity stainless steel automatic sesame dehuller, sesame skin peeling machine with low breaking rate

Product Description

Product Description
high capacity stainless steel automatic sesame dehuller, sesame skin peeling machine with low breaking rateProduct Description 1.APPLICATIONSApplied for sesame soaking, sesame skin removing, sesame skin and kernel’s separating.Collect all process together.2.MECHANICAL STRUCTURESMainly include body, composite stirrer, separator, locator, inlets and outlets, and deceleration gear box,etc.3.OPERATION PRINCIPLES I. SoakingThe special stirrer, which is driven by decelerator, puts upward the peripheral sesame seed and the center sesame will continuously move downwards, in this way, the sesame will move up and down, later the sesame soak in water totally.II. Skin removingThe stirrer driven by decelerator makes the soaked sesame rotating rapidly up and down. The hull will removed from the kernel by the friction between sesames and the rotating force from the stirrer.III. Skin and Kernel’s SepErating The hull and kernel are pushed continuously by the stirrer driven by decelerator to move in radial and axile directions. The hull is discharged through the holes on the plate, while the kernel is sustained by the plate with holes, and thus they are separated from each other. 4. SpecificationsModelCapacityPowerVoltageWeightDimensions Material TPFL-120 200-250kg/h 5.5kw 380V 800kg 1200×1430×2360mmOnly the parts touching sesame are stainless steel JPFQ-120 200-250kg/h 5.5kw 380V 800kg 1200×1430×2360mmall parts are stainless steel5. CharacteristicsAn assembly equipment combining processes of soaking, hull removing, and hull separating from kernel.Easy transport, large output within a short period of time.High hull removing rate ≥98%Vertical displacement, compact structure and large outputEasy to operate and with less maintenance. Company Information Packaging & Shipping Trade Shows Certifications

---
