| US$158,000.00-165,000.00 | 1 Piece (MOQ) |
| ITEM | UNIT | JT-4025X | |
| Workbench | Workbench size | mm | 4000*2100 |
| Worktable load-bearing capacity | kg | 12000 | |
| T-slot width (width x spacing x number of slots) | mm | 22*200*10 | |
| Trip | X-axis travel | mm | 4000 |
| Y-axis travel | mm | 2500 | |
| Z-axis travel | mm | 1200 | |
| Distance between two pillars | mm | 2500 | |
| Height from workbench to crossbeam | mm | 1500 | |
| Distance from spindle end face to workbench | mm | 200-1400 | |
| Distance from spindle center to Z-axis rail surface | mm | 495 | |
| Principal axis | Speed range | rpm | 6000 |
| Main spindle power (continuous/30 minute rated) | kw | 22/26 | |
| Spindle torque(rated for continuous/15minutes) | Nm | 140/286 | |
| Slope of spindle inner hole | BT50 | ||
| Transmission mode | Belt-type | ||
| Feed | X-axis rapid displacement | m/min | 10 |
| Y-axis rapid displacement | m/min | 12 | |
| Z-axis rapid displacement | m/min | 10 | |
| Feed rate | mm/min | 6000 | |
| Automatic tool change system | Tool magazine capacity | set | 24 |
| Maximum tool outer diameter (when fully loaded) | mm | 1 | |
| Expanding the diameter of the hollow blade | mm | 200 | |
| Maximum tool length | mm | 350 | |
| Maximum tool weight | kg | 18 | |
| Tool change time (knife to knife) | sec | 5 | |
| Precision VD13441 (JISB6338) | Positioning accuracy | mm | P0.03 |
| Repetitive accuracy | mm | P0.025 | |
| Other | Electricity dernad | Kva | 50 |
| Barometric pressure demand (minimum) | kg/cm² | 6 | |
| Cuting fluid capacity | liter | 400 | |
| Machine footprint | mm (approximately) | 11000*6000 | |
| Machine height | mm (approximately) | 5800 | |
| Machine weight | kg (approximately) | 38000 | |
